Electric signal generated under action of HF laser pulse on surface of a water column
-
摘要:研究了脉冲HF 与水柱表面相互作用下电信号的产生过程。电信号显示了与 能量线性相关的峰值间有时间间隔的两峰结构,且第二个尖峰在水柱底部的蒸汽腔塌缩后出现。实验还显示电信号的幅值和 脉冲照射过程中是否存在膨胀和挤压的薄水层密切相关。如果在电池上边缘和石英平板(石英板紧邻电池,并与水柱上表面相接)之间存在一薄水层,电信号强度会增加10倍。Abstract:Generation of an electric signal under interaction of pulsed HF laser radiation with water column surface was investigated. It was found that the electric signal demonstrates pronounced a two-peak structure with time interval between peaks linearly depending on the laser energy. The second pike was determined to appear upon the collapse of the vapor cavity produced at the bottom of water column. It was also found that the amplitude of electric signal strongly depends on the presence of a thin water layer which is dilated and pressed in the process of the water column motion initiated by laser pulse. Tenfold increase of electric signal is achieved if the thin water layer is presented between the upper border of the cell and quartz plate which closes the cell and touches the upper surface of water column.
-
Key words:
- HF laser/
- vapor cavity/
- thin water layer/
- quartz plate/
- water column
-
[1] ILYICHEV N N,KULEVSKY L A,PASHININ P P. Photovoltaic effect in water induced by a 2.92-μm Cr3+:Yb3+:Ho3+:YSGG laser[J].Quantum Electronics,2005,35:959. [2] ANDREEV S N,IL'ICHEV N N,Firsov K N,et al.. Generation of an electrical signal upon the interaction of laser radiation with water surface[J].Laser Phys.,2007,17:1041. [3] ANDREEV S N,KULEVSKY L A. Simulate the effect of electric signal generation in water by laser radiation[J]. PRYKL F., 2008,4:30. [4] ANDREEV S N,FIRSOV K N,KAZANTSEV S Y,et al.. Temporal structure of an electric signal produced upon interaction of radiation from a HF laser with the bottom surface of a water column[J].Quantum Electronics,2009,39:179 [5] SALEM R R.The Theory of Double Layer[M]. Moscow:Fizmatlit,2003:104. -
