高频信息矢量匹配实现异源图像配准

韩广良

中国科学院长春光学精密机械与物理研究所,吉林长春 130033

基金项目:

国家自然科学基金资助项目(No.60805045)

详细信息

作者简介:
韩广良(1968-),男,内蒙古满洲里人,博士,研究员,主要从事机器视觉及视频目标识别跟踪等方面的研究。 E-mail:hangl@ciomp.ac.cn

中图分类号:TP391.4
计量
- 文章访问数:3347
- HTML全文浏览量:297
- PDF下载量:1261
- 被引次数:0
出版历程
- 收稿日期:2011-07-21
- 修回日期:2011-08-23
- 刊出日期:2011-10-25

Alignment between different source images by high frequency vector matching

HAN Guang-liang

Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China

摘要

摘要:介绍了一种通过提取红外与可见图像高频信息形成矢量模型的方法,该模型可用于可见和红外两种不同波段相同场景图像的配准。分析了红外与可见图像的共同特性,即边缘高频特性,并在作为模板的图像中提取这类高频信息。利用人工干预的方法形成矢量模型,该矢量模型可通过实时姿态信息进行实时三维变换,并重新投影为二维图形,据此可在另一图像中进行特征搜索,达到两者匹配的目的。利用实际数据进行了实验分析,结果显示,利用本文算法提取的矢量模型,经变换后能可靠地实现异源目标自动识别;实验证明此方法有效可行,并可推广应用于各种异源图像间的自动目标识别和配准处理。
- 异源配准/
- 高频矢量模型/
- 实时三维变换/
- 红外与可见图像
Abstract:This article proposes a construction method of vector model based on high frequency information of infrared and visible images, which can be applied to the image alignment between different wave bands(visible and infrared) to the same scene. First, the high frequency characteristic, that is a common characteristic of infrared and visibility images, is analyzed, and it is picked up from a model image. A vector model is constructed by manual interposing. Then, the vector model is performed a 3D transform by the real-time attitude information, and is projected into a 2D graph again, which can be used to carry out the characteristic searching, and achieve the image matching. Finally, matching experiments are performed, and the vector model after transform can complete the image target automatic recognition for different sources. The theoretical analysis and experiment results prove the efficiency and feasibility of this method, and show it popular to all kinds of image alignments that come from different image sources.
- different source image alignment/
- high frequency vector model/
- real-time 3D transform/
- infrared and visible images

HTML全文

参考文献 (1)

[1] 倪国强,刘琼. 多源图像配准技术分析与展望[J]. 光电工程 ,2004,31(9):1-6. NI G Q,LIU Q. Analysis and prospect of multi-source image registration techniques[J].Opto-Electronic Eng.,2004,31(9):1-6.(in Chinese) [2] 刘婧,孙继银,朱俊林,等. 前视红外景象匹配制导基准图生成研究[J]. 微计算机信息 ,2007,23(10):279-281. LIU J,SUN J Y,ZHU J L,et al.. Study on the generate of reference image on the guidance of FLIR scene matching[J].Microcomputer Information,2007,23(10):279-281.(in Chinese) [3] 李俊山,李旭辉,罗蓉,等. 不同传感器图像的景象匹配区选取准则研究[J]. 微电子学与计算机 ,2007,24(1):210-213. LI J SH,LI X H,LUO R,et al.. Research on selection criterion of scene matching field for different sensors[J].Microelectronics&Computer,2007,24(1):210-213.(in Chinese) [4] RIZVI S A,NASRABADI N M. Fusion of FLIR automatic target recognition algorithms[J].Information Fusion,2003,4(4):247-258. [5] 张天序,曹杨,刘进,等. 基于不变矩的前视红外图像机场目标识别[J]. 华中科技大学学报(自然科学版) ,2007,35(1):17-19. ZHANG T X,CAO Y,LIU J,et al.. Recognition of airfields in forward looking infrared image sequences by affine moment invariants[J].J. Huazhong University Science and Technology(Nature Science),2007,35(1):17-19.(in Chinese) [6] 刘琼,倪国强,周生兵. 图像配准中几种特征点提取方法的分析与实验[J]. 光学技术 ,2007,33(1):62-67. LIU Q,NI G Q,ZHOU SH B. Experiments and analysis of several feature extraction methods for image registration[J].Optical Technique,2007,33(1):62-67.(in Chinese) [7] 赵鹏,浦昭邦,张田文. 一种新的红外与可见光图像融合与跟踪方法[J]. 光电工程 ,2005,32(2):37-40. ZHAO P,PU ZH B,ZHANG T W. Fusion and tracking for IR and visible images[J].Opto-Electronic Eng.,2005,32(2):37-40.(in Chinese) [8] 张天序.成像自动目标识别[M]. 武汉:湖北科学技术出版社,2005. ZHANG T X.Atomated Recognition of Imaged Target[M]. Wuhan:Hubei Science and Technology Press,2005. [9] 党宏涛,张胜修. 光学前视在巡航导弹地形跟踪中的应用与仿真[J]. 弹箭与制导学报 ,2007,27(2):71-73. DANG H T,ZHANG SH X. Application and simulation of optical forward vision system for cruise missile's terrain following[J].J. Projectiles, Rockets, Missiles and Guidance,2007,27(2):71-73.(in Chinese) [10] 谭皓,王金岩,沈春林,等. 巡航导弹中制导阶段航迹规划算法[J]. 南京航空航天大学学报 ,2005,37(1):1-5. TAN H,WANG J Y,SHEN CH L,et al.. Trajectory programming algorithm for cruise missile guidance[J].J. Nanjing University Aeronautics&Astronautics,2005,37(1):1-5.(in Chinese) [11] 魏伟波,芮筱亭. 精确制导技术研究[J]. 火力与指挥控制 ,2006,31(2):5-10. WEI W B,RUI X T. Study on precision guidance technology[J].Fire Control and Command Control,2006,31(2):5-10.(in Chinese) [12] 杨树谦. 精确制导技术发展现状与展望[J]. 航天控制 ,2004,22(4):17-20. YANG SH Q. Development and prospect of PGM technology[J].Aerospace Control,2004,22(4):17-20.(in Chinese) [13] 王甜,王建民,杨树谦,等. 红外图像自动目标识别技术发展[J]. 飞航导弹 ,2005(11):45-47. WANG T,WANG J M,YANG SH Q,et al.. Development of IR image auto target recognition technology[J].Winged Missiles J.,2005(11):45-47.(in Chinese) [14] 杨卫平,沈振康. 红外成像导引头及其发展趋势[J]. 与红外 ,2007,37(11):1129-1133. YANG W P,SHEN ZH K. Infrared image seeker technique and its development trend[J].Laser&Infrared,2007,37(11):1129-1133.(in Chinese) [15] FLEEMAN E L. Technologies for future precision strike missile systems introduction/overview. RTO SCI Lecture Series on "Technologies for Future Precision Strike Missile Systems",Atlanta,USA,23-24 March,2000. [16] RIEDL G,ASSEL M,FENDT A,et al.. IR focal plane array seekers for ground-to-ground and air-to-ground missiles[J].SPIE,2001,4369:201-209.
