冷铷原子样品中高效静态光信号的生成与调制

张岩; 张晓航; 张宇; 崔淬砺; 国秀珍; 吴金辉

doi:10.3788/CO.20120502.0143

冷铷原子样品中高效静态光信号的生成与调制

doi: 10.3788/CO.20120502.0143

1.
吉林大学物理学院, 吉林长春 130012;
2.
长春理工大学光电信息学院, 吉林长春 130012

基金项目:

吉林大学研究生创新基金资助项目(No.20101051)

详细信息

中图分类号: O431.2
计量
- 文章访问数: 3581
- HTML全文浏览量: 483
- PDF下载量: 816
- 被引次数: 0
出版历程
- 收稿日期: 2011-11-11
- 修回日期: 2012-01-13
- 刊出日期: 2012-04-10

Generation and modulation of high efficiency stationary optical signals in cold ⁸⁷ Rb atomic samples

1.
College of Physics, Jilin University, Changchun 130012, China;
2.
College of Optical and Electronical Information, Changchun University of Science and Technology, Changchun 130012, China

摘要

摘要: 为了提高光信息处理元件的性能,实现高效率光信号的静止与存储,本文建立了由双向耦合场耦合的冷铷(87Rb)原子的四能级双型能级机制,并对此机制在生成静态光信号时要求的高效性、持续时间,控制耦合场所需的操作条件以及对信号场强度的相位调制等进行了研究。首先,选取四能级双型87Rb冷原子精细能级,用一对反向传播的行波场对能级进行近共振耦合,并沿耦合场方向输入一个正向弱光信号进行探测。接着,通过适当的绝热开启、关闭耦合场,存储光信号和生成高保真度静态光信号。然后,通过选取87Rb原子的不同精细能级结构,得出实现静态光所需满足的必要条件。最后,采用相位调制法对光信号进行处理。结果表明:生成的静态光信号具有高效性,过程持续时间约为80 s;相位调制法可以周期调节静态光脉冲的强度。在此机制下生成的静态光信号满足高效性、易于全光调节和长时效性等要求。
- 电磁感应光透明 /
- 87Rb原子 /
- 四能级系统 /
- 静态光脉冲 /
- 动态光存储
Abstract: In order to improve the performance of optical information processing components and to achieve high efficiency optical signals for static storage, a four-level double-Lambda cold 87Rb atomic system driven by two counter-propagating travelling wave fields is established, and the necessary Stationary Pulse Light(SLP) conditions of controlling coupling fields and phase modulation ways to control probe intensity are studied. First, the four-level double-Lambda cold 87Rb atomic energy level driven by two counter-propagating travelling wave fields is selected, and the forward resonance coupling field is switched on to guide only one forward incident signal into samples for detection. Then, the optical signals are stored and efficient SLPs are generated through switching on and turning off two coupling fields. The necessary conditions to generate efficient SLPs are obtained according to selecting different fine structures of energy level. Finally, the phase modulation method of control stationary light intensity is attained. The results indicate that the system can generate efficient SLPs with continue time nearly 80 s and the phase modulation can adjust the stationary light intensity periodically. Obtained SLPs satisfy the optical signal processing requirements for higher efficiency, higher fidelity, all-optical control and long timeliness.
- Electromagnetically Induced Transparency(EIT) /
- 87Rb atom /
- four-level system /
- Stationary Pulse Lights(SPLs) /
- dynamic light storage

HTML全文

参考文献(1)

[1] KIMBLE H J. The quantum internet[J]. Nature,2008,453:1023-1030. [2] HAMMERER K. Quantum interface between light and atomic ensembles[J]. Rev. Mod. Phys.,2010,82:1041-1093. [3] BAJCSY M,ZIBROV A S,LUKIN M D. Stationary pulses of light in an atomic medium[J]. Nature,2003,426:638-641. [4] CUI C L,JIA J K,WU J H,et al.. Ultraslow and superluminal light propagation in a four-level atomic system[J]. Phys. Rev. A,2007,76:033815. [5] PUGATCH R,SHUKER M,FIRSTENBERG O,et al.. Topological stability of stored optical vortices[J]. Phys. Rev. Lett.,2007,98:203601. [6] CHOI K S,DENG H,LAURAT J,et al.. Mapping photonic entanglement into and out of a quantum[J]. Nature,2008,452:67-71. [7] ANDRE A,LUKIN M D. Manipulating light pulses via dynamically controlled photonic band gap[J]. Phys. Rev. Lett.,2002,89:143602. [8] WU J H,LAROCCA G C,ARTONI M. Controlled light-pulse propagation in driven color centers in diamond[J]. Phys. Rev. B,2008,77:113106. [9] ZHANG Y,XUE Y,WANG G,et al.. Steady optical spectra and light propagation dynamics in cold atomic samples with homogeneous or inhomogeneous densities[J]. Opt. Express,2011,19:2111-2119. [10] ZHAO L,WANG T,YELIN S E. Two-dimensional all-optical spatial light modulation with speed in coherent media[J]. Opt. Lett.,2009,34:1930-1932. [11] de CARVALHO S A,de ARAUJO L E E. Electromagnetically-induced phase grating:A coupled-wave theory analysis[J]. Opt. Express,2011,19:1936-1944. [12] BAJCSY M,ZIBROV A S,LUKIN M D. Stationary pulses of light in an atomic medium[J]. Nature,2003,426:638-641. [13] WU J H,ARTONI M,LAROCCA G C. All-optical light confinement in dynamic cavities in cold atoms[J]. Phys. Rev. Lett.,2009,103:133601. [14] LIN Y W,LIAO W T,PETERS T,et al.. Stationary light pulses in cold atomic media and without bragg gratings[J]. Phys. Rev. Lett.,2009,102:213601. [15] WU J H,ARTONI,LAROCCA G C. Decay of stationary light pulses in ultracold atoms[J]. Phys. Rev. A,2010,81:033822. [16] WANG D W,LI Z H,ZHENG H,et al.. Time evolution, Lamb shift, and emission spectra of spontaneous emission of two identical atoms[J]. Phys. Rev. A,2010,81:043819. [17] WANG L G,QAMAR S,ZHU S Y,et al.. Manipulation of the Raman process via incoherent pump, tunable intensity, and phase control[J]. Phys. Rev. A,2008,77:033833. [18] HAO X Y,LI L H,LÜ X Y,et al. Controllable amplification and absorption properties in coupled-double-quantum-wells with tunneling-induced interference[J]. Eur. Phys. J. D,2010,56:239-246.
