Real-time measurement of dynamic horizontal attitudes of ships based on optical method
-
摘要:针对测量船传统实时水平测量方法精度较低(10.0)的问题,引入了基于光学测量手段的动态实时船体水平姿态测量方法。采用光学编码精密测角+惯性同步复示平台+水平误差检测工具的设计模式,保证了跟踪的稳定性,提高了测量精度。实验结果表明:提出的方法可以提供比传统惯导系统更稳定、精度更高(纵摇5.37,横摇3.60)的船体水平姿态数据;可以作为一种普遍适用的运动载体精密水平测量监测手段,为运动载体实时提供高精度的水平基准信息,或用于运动载体惯导水平精度鉴定等。Abstract:In order to solve the problem of low accuracy( 10 arcsec) in traditional real-time horizontal measurement methods, this paper introduces a new real time measurement method for the dynamic attitudes of a survey ship based on optical measurement. The model of precise optical angle encoder measurement+inertia synchronous duplex platform+horizontal attitude error detection tool is designed to ensure the tracking stability and to improve the measurement accuracy. Experimental results show that this method can provide more stable attitude data of the survey ship with greater precision(pitch:5.37 arcsec, rolling:3.60 arcsec) than those of the traditional Inertial Navigation System(INS). As a universal standard of precise measurement for moving carriers, this design can provide accurate real-time level of baseline information, or the accuracy level for INS accreditation of moving carriers.
-
[1] 冯小勇. 运动载体实时精密水平测量方法:中国,200910046330.3. 2010-04-21. FENG X Y. Real-time precision horizontal measurement method for motion carrier:CN,200910046330.3. 2010-04-21.(in Chinese) [2] 张志远,罗国富. 舰船姿态坐标变换及稳定补偿分析[J]. 舰船科学技术,2009,31(4):34-40. ZHANG ZH Y,LUO G F. Coordinate transformation of warship pose and analysis of stabilization compensation[J].Ship Sci. Technology,2009,31(4):34-40.(in Chinese) [3] 杨振,李广云,黄桂平. 基于自准直的立方镜姿态测量方法研究[J]. 宇航计测技术,2010,56(2):14-17. YANG ZH,LI G Y,HUANG G P. Research on attitude measurement method of cubic prism based on auto-collimation[J].J. Astronautic Metrology and Measurement,2010,56(2):14-17.(in Chinese) [4] 黄祥, 吴年祥. 基于PSD的光电自准直仪角度测量系统研究[J]. 制造业自动化,2011,33(11):39-41. HUANG X,WU N X. The research photoelectric autocllimator angle measurement system based on PSD[J].Manufacturing Automation,2011,33(11):39-41.(in Chinese) [5] 霍志,刁节涛,李清江. 基于PXIE总线的高速CCD数字图像采集系统设计[J]. 现代电子技术,2011,34(14):88-92. HUO ZH,DIAO J T,LI Q J. Design of high-speed CCD digital image collecting system based on PXIE bus[J].Modern Electronic Technique,2011,34(14):88-92.(in Chinese) [6] 曹晖,毕建峰. 基于PXI总线的实时综合测试系统研究[J]. 上海航天,2011,38(3):64-68. CAO H,BI J F. Research of PXI-based real-time integrated measurement system[J].Aerospace Shanghai,2011,38(3):64-68.(in Chinese) [7] 宋连龙,陈虹丽. 舰船姿态运动的自适应实时预报及其应用[J]. 船电技术,2005,25(4):40-42. SONG L L,CHEN H L. Real-time self-adaptive prediction system and its application on ship attitude motion[J].Marine Electric Electronic Technology,2005,25(4):40-42.(in Chinese) [8] 易东云,吴孟达. 船姿数据的模型误差与噪声误差分析[J]. 导弹与航天运载技术,1998,232(2):41-44. YI D Y,WU M D. Analysis for model error and noise error of ship posture data[J].J Missiles and Space Vehicles,1998,232(2):41-44.(in Chinese) [9] 王恒,李永刚,陈亮. 测量船船摇前馈数据处理方法研究及应用[J]. 飞行器测控学报,2011,30(2):64-69. WANG H,LI Y G,CHEN L. Processing of the shaking feedforward data of space instrumentation ships[J].J. Spacecraft TT&C Technology,2011,30(2):64-69.(in Chinese)
