基于Norland紫外固化胶的热光开关器件

doi:10.3788/CO.20120502.0194

吉林大学电子科学与工程学院集成光电子学国家重点联合实验室, 吉林长春130012

基金项目:

国家自然科学基金资助项目(No.61077041,No.60807029);吉林省青年科研基金资助项目(No.20100174);吉林大学基本科研业务费专项资金资助项目(No.200810028,No.200905005,No.201100253)

详细信息

中图分类号:TN252
计量
- 文章访问数:3060
- HTML全文浏览量:238
- PDF下载量:804
- 被引次数:0
出版历程
- 收稿日期:2011-11-21
- 修回日期:2012-01-23
- 刊出日期:2012-04-10

Thermo-optic switch device based on Norland optical adhesive

State Key Laboratory on Integrated Optoelectronics, College of Electronic Science and Engineering, Jilin University, Changchun 130012, China

摘要

摘要:采用新型聚合物材料Norland紫外固化胶(NOA)制备了聚合物M-Z型热光开关器件。对NOA薄膜材料的光学性质进行了表征,采用感应耦合等离子体(ICP)方法制备出形貌良好的波导器件。测得在1 550 nm波长下,长2.2 cm的直波导插入损耗为8.3 dB。在电极上施加直流信号,测得热光开关的消光比为11 dB,驱动功率为85 mW。引入直流偏置网络,获得了器件的开关特性曲线,测得开关器件的上升时间为1.085 ms,下降时间为489.5 s。实验结果表明:NOA材料在热光开关及其它聚合物光波导集成器件的制备中具有很大的应用潜力。
- 平面光波导/
- 聚合物光波导/
- 热光开关/
- Norland紫外固化胶
Abstract:Norland Optical Adhesive(NOA), a new type of polymer material, is used to fabricate the Mach-Zehnder thermo-optic switch in this paper. The optical properties of NOA film materials are characterized. The waveguides with good profiles are fabricated by the Inductively Coupled Plasma(ICP) method. The insertion loss of a 2.2 cm-length straight waveguide is 8.3 dB at 1 550 nm. The extinction ratio of the thermo-optic switch is 11 dB and the driving power is 83 mW when the DC bias is loaded on the electrodes. The switching property of the device is tested with DC bias, and the rise time and the fall time of the switch are 1.085 ms and 489.5 s, respectively. Experimental results show that the NOA material has great potentials in fabricating thermo-optic switches and other polymer waveguide integrated devices.
- planar optical waveguide/
- polymer optical waveguide/
- thermo-optic switch/
- Norland Optical Adhesive(NOA)

HTML全文

参考文献 (1)

[1] SIEBEL U,HAUFFE R,PETERMANN K. Crosstalkenhanced polymer digital optical switch based on a W-shape[J].IEEE Photon. Techonl. Lett.,2000,12(1):40-41. [2] OH M C,LEE H J,LEE M H,et al.. Asymmetric X-junction thermooptic switches based on fuluorinated polymer waveguides[J].IEEE Photon. Technol. Lett.,1998,10(6):813-815. [3] HIDA Y,OOBA N,YOSHIMURA R,et al.. Influence of humidity on transmistion in a Y-branch thermo-optic switch composed of deuterated fluoromethacrylate polymer waveguides[J].Electron. Lett.,1997,33(7):626-627. [4] DIEMEER M B J,BRONS J J,TROMMEL E S. Polymer optical waveguide switch using the thermooptic effect[J].J Lightwave Techonl.,1997,7(3):449-453. [5] 王微. 低功耗聚合物Mach-Zehnder 热光开关的研制[J]. 光子学报,2010,39(4):610-613. WANG W. Low power consumption polymer thermo-optic switch with Mach-Zehnder interferometer[J].Acta Photonica Sinica,2010,39(4):610-613.(in Chinese) [6] 高磊. 基于负型光刻胶SU-8的光开关的研究. 长春:吉林大学,2010. GAO L. Research of optical switches based on negative photoresist SU-8. Changchun:Jilin University,2010.(in Chinese) [7] WAGLI P,HOMSY A,DE ROOIJ N F. Norland optical adhesive(NOA81) microchannels with adjustable surface properties and high chemical resistance against IR-transparent organic solvents[J].Procedia Eng.,2010,5:460-463. [8] KIM Y S,LEE N Y,LIM J R. Nanofeature-patterned polymer mold fabrication toward precisely defined nanostructure replication[J].SPIE,2005,17:5867-5870. [9] SINGHAL R,SATYANARAYAN M N,PAL S. Effect of residual resist on performance of single-mode 1×4 optical splitter in photosensitive polymer[J].Fiber and Integrated Opt.,2010,29:480-490. [10] LIU J,SUN Y,FAN X D. Highly versatile fiber-based optical Fabry-Perot gas sensor[J].Opt. Express,2009,17(4):2731-2738. [11] TSANG K CH,WONG CH Y,PUN E Y B. High-gain optical amplification in Eu³⁺-doped polymer[J].Opt. Lett.,2010,35(4):520-522. [12] KIM J W,KIM K J,OH M CH. Plastic optical pressure sensors using a flexible polymer waveguide //Integrated Photonics and Nanophotonics Research and Applications(IPNRA). Honolulu,Hawaii,USA,July 17,2009.
