离轴三反测绘相机调焦机构的设计

doi:10.3788/CO.20120504.0373

中国科学院长春光学精密机械与物理研究所, 吉林长春 130033

基金项目:

国家自然科学基金资助项目(No.60507003)

详细信息

通讯作者:
邵明东

中图分类号:V245.6;TH703
计量
- 文章访问数:3110
- HTML全文浏览量:429
- PDF下载量:1347
- 被引次数:0
出版历程
- 收稿日期:2012-03-12
- 修回日期:2012-05-13
- 刊出日期:2012-08-10

Design of focusing mechanism for off-axis TMA mapping cameras

Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China

摘要

摘要:针对测绘相机对相机成像质量和内方位元素稳定性的要求,在分析3种调焦方式特点的基础上,确定了符合离轴三反测绘相机需要的调焦方式。设计了滚珠丝杠驱动的直线导轨式调焦机构,计算得到调焦机构的灵敏度为0.2 m。对该调焦机构进行了精度检测和试验验证,结果显示其指向精度2,定位精度3 m。得到的结果表明:该空间调焦机构具有结构紧凑、刚度高、位移精度好等特点,能够满足离轴三反测绘相机的调焦要求。
- 离轴三反测绘相机/
- 调焦机构/
- 调焦精度/
- 光学设计
Abstract:Based on the requirements of mapping cameras for imaging quality and the stability of inner orientation elements, the characteristics of three focusing strategies are analyzed in detail, and the strategy which is most suitable for the mapping cameras is confirmed. A ball screw driving linear-guide-type focusing mechanism is designed, and its focusing sensitivity is calculated to be 0.2 m. Precision testing and test validation are performed, which shows that the pointing accuracy of the focusing mechanism is superior to 2 and the positioning accuracy of the focusing mechanism is better than 3 m. Test results demonstrate that the designed focusing mechanism has the characteristics of compact structure, high stiffness and high displacement precision and it can meet the focusing requirements of off-axis TMA mapping cameras.
- off-axis Three Mirror Anastigmat(TMA) mapping camera/
- focusing mechanism/
- focusing accuracy/
- optical design

HTML全文

参考文献 (1)

[1] 丁亚林,田海英,王家琪. 空间遥感相机调焦机构设计[J]. 光学精密工程 ,2001,9(1):36-38. DING Y L,TIAN H Y,WANG J Q .Design on the focusing mechanism of space remote-sensing camera[J].Opt. Precision Eng.,2001,9(1):36-38.(in Chinese) [2] 张新洁,颜昌翔,谢涛. 星载光学遥感器调焦机构的设计[J]. 光学精密工程 ,2009,17(11):2757-2761. ZHANG X J,YANG CH X,XIE T. Design of focusing mechanism of space remote sensor[J].Opt. Precision Eng.,2009,17(11):2757-2761.(in Chinese) [3] 胡君,王栋,孙天宇. 现代航天光学成像遥感器的应用与发展[J]. 中国光学与应用光学 ,2010,3(6):520-526. HU J,WANG D,SUN T Y. Application and development of recent space optical imaging remote sensors[J].Chinese J.Opt. Appl. Opt.,2010,3(5):520-526.(in Chinese) [4] 卢锷,颜昌翔,吴清文,等. 空间光学遥感器环境适应性设计与试验研究[J]. 中国光学与应用光学 ,2009,2(5):365-370. LU E,YAN CH X,WU Q W,et al.. Research on adaptability of optical remote sensors in mechanical and space thermal environments[J].Chinese J. Opt. Appl. Opt.,2009,2(5):365-370.(in Chinese) [5] 张新洁,王树清,颜昌翔. 空间相机调焦机构的设计与分析[J]. 中国光学与应用光学 ,2010,3(5):462-465. ZHANG X J,WANG SH Q,YANG CH X. Design and analysis for focusing mechanism of space camera [J].Chinese J. Opt. Appl. Opt.,2010,3(5):462-465.(in Chinese) [6] 黄和平,夏寅辉,安成斌,等. 大口径、长焦距红外系统调焦机构设计[J]. 与红外 ,2005,35(10):745-747. HUANG H P,XIA Y H,AN CH B,et al.. Design on the focusing mechanism of long focus IR system[J].Laser&Infrared,2005,35(10):745-747.(in Chinese) [7] 安源,齐迎春. 空间相机直线调焦机构的设计[J]. 光学精密工程 ,2009,17(3):609-614. AN Y,QI Y CH. Design of straight-line focusing mechanism for space camera[J].Opt. Precision Eng, 2009,17(3):609-614.(in Chinese) [8] 李朝晖,王智,乔克,等. 三线阵立体测绘相机高精度调焦技术及实现[J]. 光电工程 ,2009,36(10):41-46. LI ZH H,WANG ZH,QIAO K,et al.. Focusing technique for three-line stereo mapping camera and realization[J].Opto-Electronic Eng.,2009,36(10):41-46.(in Chinese) [9] 胡莘,曹喜滨. 三线阵立体测绘卫星的测绘精度分析[J]. 哈尔滨工业大学学报 ,2008,40(5):695-699. HU X,CAO X B. Analysis on precision of stereo mapping microsatellite using three-line array CCD images[J].J. Harbin Institute Technology,2008,40(5):695-699.(in Chinese) [10] 费业泰.误差理论与数据处理[M]. 4版.北京:机械工业出版社,2003. FEI Y T.Error Theroy and Data Processing[M].4th ed. Beijing:China Machine Press,2003.(in Chinese)
