Design of wavefront-guided lens based on individual eye optical model
-
摘要:提出一种在个体眼光学结构基础上根据波前数据设计波前眼镜的新方法。建立了个性化的眼光学结构,并将眼球和镜片视为统一的镜-眼光学系统,用光学设计的优化方法给出镜片的结构数据,并分析了7视场和眼球旋转20时,该镜-眼系统的成像情况。与波前拟合的方法相比,该方法设计的波前眼镜离焦差为(-0.0570.015) m-1,像散差为(0.0150.013) m-1,散光轴位差为(0.1000.316)。镜-眼系统的矫正视力均大于1.25,其中8只被试眼的视力可达1.5以上。10只被试眼在转动20情形下的0视场成像相比于直视的情况均略有下降,而7视场的成像质量相比于直视的情况下降则更为明显。由该方法给出的验光结果客观可信,可用于对佩戴波前眼镜后人眼的视觉质量的预先评估。Abstract:A new method to design a wavefront-guided lens is proposed based on an individual eye optical model. The individual eye model is constructed, then by regarding the eyeball and the wavefront-guided lens as a single system. For the lens-eye system, the surface profiles of the lens are determined by optimizing the lens design. In addition, the visual performance of the lens-eye system is analyzed for both ?7? field of view and ?20? rotation of the eyeball. In comparison with the results from wavefront fitting, the prescription difference in defocus, astigmatism and in the axis of astigmatism are (-0.057?0.015) m-1, (0.015?0.013) m-1, (0.100?0.316)?, respectively. Furthermore, the visual acuity of the lens-eye system is above 1.25 because of the correction of the wavefront-guided lens. The visual acuity for the eight eyes is as high as 1.5. For a field of view of 0?, the performance for the eye without rotation is better than that of eyes with a rotation of 20?. However, for a field of view of 7?, the performance for eyes without rotation is much better than that of eyes with a rotation of ?20?. Experiments show that the prescription of the wavefront-guided lens from the new method is objective and reliable and it is possible to predict the visual quality of the eye with the wavefront-guided lens.
-
[1] RUBIN M L. Spectacles:past, present and future[J].Surv Ophthalmol.,1986,30(5):321-327. [2] LIANG J Z,GRIMM H,GOELZ S,et al.. Objective measurement of wave aberrations of the human eye with the use of a Hartmann-Shack wave-front sensor[J].J. Opt. Soc. Am. A.,1994,11(7):1949-1957. [3] THIBOS L N,HONG X,BRANDLEY A. Accuracy and precision of objective refraction from wavefront aberrations[J].J. Vis.,2004,4(4):329-351. [4] ATCHISON D A,SCOTT D H,CHARMAN W N. Hartmann-Shack technique and refraction across the horizontal visual field[J].J. Opt. Soc. Am. A.,2003,20(6):965-973. [5] SALMON T O,THIBOS L N. Videokeratoscope-line-of-sight misalignment and its effect on measurements of corneal and internal ocular aberrations[J].J. Opt. Soc.Am. A.,2002,20(1):657-669. [6] THIBOS L N,WHEELER W,HORNER D. Power vectors:an application of Fourier analysis to the description and statistical analysis of refractive error[J].Optom. Vis. Sci.,1997,74(6):367-375. [7] WILLIAM H S,JANET P. Clinical investigation into the vision performance provided by the zon spectacle lens system[J].Rev. Optom.,2008,10(15):1-15. [8] LIOU H,BRENNAN N A. Anatomically accurate, finite model eye for optical modeling[J].J. Opt. Soc. Am.,1997,14(8):1684-1695. [9] GARNER L F,SMITH G. Changes in equivalent and gradient refractive index of the crystalline lens with accommodation[J].Optom. Vis. Sci.,1997,74(2):114-119. [10] WANG W,WA ZH Q,WANG Y,et al.. Wave-front aberrations of cornea and crystalline lens[J].Chin. Phys. Lett.,2006,23(3):607-609. [11] 瞿佳,姚进.眼镜学[M]. 北京:人民卫生出版社,2004:58-62. QU J,YAO J.Spectacles[M]. Beijing:People's Medical Publishing House,2004:58-62.(in Chinese) [12] GE J J,W ZH Q,WANG Y,et al.. Characteristics and new measurement method of NCSFs of individual color mechanisms of human vision[J].Chin. Phys. Lett.,2010,27(5):054201(1-4). [13] 王之江,顾培森.实用光学技术手册 [M]. 北京:机械工业出版社,2007:618-620. WANG ZH J,GU P S.Handbook for Practical Optical Techniques[M]. Beijing:Chine Medicine Press,2007:618-620(in Chinese)
