组合式发光二极管路灯反射器的设计

doi:10.3788/CO.20120505.0520

赵亚辉,
范长江^,

浙江师范大学信息光学研究所, 浙江金华 321004

基金项目:

浙江省自然科学基金资助项目(No.Y1100524);浙江师范大学创新团队和浙江师范大学博士启动基金资助项目(No.zc304009158)

详细信息

作者简介:
赵亚辉(1989-),女,河北邯郸人,硕士研究生,主要从事光学系统设计等方面的研究。 E-mail:zhaoyahui@163.com 范长江(1974-),男,山东临沂人,博士,讲师,主要从事二元光学、LED应用照明等方面的研究。 E-mail: fancj@zjnu.cn
赵亚辉(1989-),女,河北邯郸人,硕士研究生,主要从事光学系统设计等方面的研究。 E-mail:zhaoyahui@163.com 范长江(1974-),男,山东临沂人,博士,讲师,主要从事二元光学、LED应用照明等方面的研究。 E-mail: fancj@zjnu.cn

通讯作者:
范长江

中图分类号:O439;TM923.58
计量
- 文章访问数:2947
- HTML全文浏览量:210
- PDF下载量:805
- 被引次数:0
出版历程
- 收稿日期:2012-07-16
- 修回日期:2012-08-18
- 刊出日期:2012-10-10

Design of combined reflectors used in LED street lamps

ZHAO Ya-hui,
FAN Chang-jiang^,

Institute of Information Optics, Zhejiang Normal University, Jinhua 321004, China

摘要

摘要:设计了一组合式路灯反射器,以使发光二极管(LED)路灯在道路照明时产生矩形光斑和均匀照度。在非成像光学基础上,利用复合抛物面的高性能集光作用和机械设计软件的强大作图功能,设计了一款分段组合复合抛物面反射器(CPC)。基于边缘光线原理和裁剪法,此款反射器能将朗伯型发光的LED光束整形为近似矩形分布,出光效率达96%以上。理论模拟证明:在高度为10 m,范围为10 m30 m内利用此反射器进行二次配光的LED路灯的照度均匀度达0.5以上。该反射式LED路灯光束整形器结构简单,光学效率高、成本低廉,模拟结果完全达到了目前我国国家道路照明规范要求。
- 发光二极管(LED)/
- 非成像光学/
- 复合抛物面反射器(CPC)/
- LED路灯/
- 光学设计
Abstract:A combined reflector for Light Emitting Diode(LED) street lamps is designed to produce a rectangular light spot and uniform lighting in the road, as well as having a simple structure and high light efficiency. Based on the principles of non-imaging optics and mechanical design software, a segmented compound parabolic reflector was designed. The reflecting beams of light from the reflector have an approximately rectangular distribution while the light efficiency can reach 96%. The analysis and simulation results show that the uniformity of illuminance can reach 0.5 over an area of 10 m?30 m when the LED lamp is installed at a height of 10 m. The reflector design when applied to shaping the LED beam into the rectangle shape has a high optical efficiency and low costs. The simulation results show that it can satisfy the current requirement for road lighting.
