机载双视场中波红外光学系统优化设计

doi:10.3788/CO.20120506.0596

1.
长春理工大学空间光电技术研究所,吉林长春,130022;
2.
中国科学院长春光学精密机械与物理研究所,吉林长春,130033;
3.
第二炮兵驻北京军代室,北京 100039;
4.
中国人民解放军海军91329部队装备部,山东威海 264200

基金项目:

教育部博士学科重点专向科研基金资助项目(No.20070189001);国家自然科学基金资助项目(No.61077056)

详细信息

通讯作者:
董科研

中图分类号:TN216
计量
- 文章访问数:2481
- HTML全文浏览量:180
- PDF下载量:960
- 被引次数:0
出版历程
- 收稿日期:2012-09-19
- 修回日期:2012-11-16
- 刊出日期:2012-12-10

Design of an airborne dual field-of-view middle wave infrared optical system

1.
Institute of Space-electronic Technology,Changchun University of Science and Technology,Changchun 130022,China;
2.
Changchun Institute of Optics,Fine Mechanics and Physics, Chinese Academy of Sciences,Changchun 130033,China;
3.
Military Representative Office of PLA 2nd Artillery in Beijing,Beijing 100039,China;
4.
Equipment department of No.91329 Troop,the People's Liberation Army Navy,Weihai 264200,China

摘要

摘要:为了满足机载红外搜索与跟踪系统的实际使用要求,根据变焦系统的基本理论及中波红外系统的特点,设计了320 pixel256 pixel的中波制冷型焦平面阵列探测器的双视场中波红外光学系统。系统采用了二次成像结构,并在系统的第一像面位置安装光阑,以此减小杂散光对系统的影响。设计结果表明:系统具有100%冷光栏效率,在仅移动一片透镜的情况下可实现在800和400 mm的两档变焦,系统F数为4且恒定不变,像面保持稳定,系统场曲＜0.04 mm,畸变＜2.5%,在探测器的Nyquist频率16 lp/mm处光学传递函数的峰值＞0.5,表明光学系统的像质满足使用要求。
- 中波红外光学系统/
- 光学设计/
- 双视场/
- 机载/
- 搜索与跟踪系统
Abstract:In order to meet the practical requirement of airborne infrared searching and tracking systems, a dual Field-of-View(FOV) middle wave(MW) infrared optical system is designed based on the MW cooled detector with 320 pixel?250 pixel and a staring focal plane array. The system adopts the secondary imaging structure and a shield is installed in the first image surface station to reduce the stray light effect. The design results show that the system has a 100% cold shield efficiency; F number of the system keeps a constant as 4 and the image surface remains stable when only one piece of the optical lens is moved to switch the focus length between 800 mm and 400 mm; the field curvature and the distortion are less than 0.04 mm and 2.5%, respectively, and the MTF is more than 0.5 at 16 lp/mm. Obtained results demonstrate that the image quality meets the operational requirement.
- middle wave infrared optical system/
- optical design/
- dual field of view/
- airborne/
- searching and tracking system

HTML全文

参考文献 (1)

[1] DOV F,ZINOVY E,ARIE C. Dichroic beamsplitter for a dual-wavelength camera in a long-range airborne reconnaissance system[J].SPIE,2005,5783:827-834. [2] 唐大为,孙强,王健,等. 折/衍混合的红外双视场光学系统设计[J]. 光子学报 ,2010,39(11):2062-2067. TANG D W,SUN Q,WANG J,et al.. Design of hybrid refractive diffractive dual field of view infrared optical system[J].Acta Photonica Sinica,2010,39(11):2062-2067.(in Chinese) [3] 郜洪云,熊涛. 中波红外两档变焦光学系统[J]. 光学精密工程 ,2008,16(10):1891-1894. GAO H Y,XIONG T. Design of middle infrared continuous system[J].Opt. Precision Eng.,2008,16(10):1891-1894.(in Chinese) [4] MANN A. Infrared zoom lenses in the 1990s[J].Opt. Eng.,1994,33(1):109-115. [5] 陈吕吉,陈津津,李萍. 新颖变焦双视场长波红外光学系统设计[J]. 红外技术 ,2011,33(7):406-410. CHEN L J,CHEN J J,LI P. A novel step-zoom LW infrared dual field-of-view optical system design[J].Infrared Technology,2011,33(7):406-410.(in Chinese) [6] 杨乐,孙强,王健,等. 长波红外连续变焦光学系统设计[J]. 红外与工程 ,2012,41(4):999-1004. YANG L,SUN Q,WANG J,et al.. Design of long-wave infrared continuous zoom optical system[J].Infrared and Laser Eng.,2012,41(4):999-1004.(in Chinese) [7] 张鑫,贾宏光. 大相对孔径红外消热差物镜设计[J]. 中国光学 ,2011,4(4):374-379. ZHANG X,JIA H G. Optical design of infrared athermalized objective with large relative aperture[J].Chinese Optics,2011,4(4):374-379.( in Chinese) [8] 程欣,张葆,洪永丰,等. 机载高光通量双波段成像光谱仪的设计[J]. 红外与工程 ,2012,41(3):690-695. CHENG X,ZHANG B,HONG Y F,et al.. Optical design of an airborne dual-wavelength imaging spectrometer with high throughput[J].Infrared and Laser Eng.,2012,41(3):690-695(in Chinese) [9] 白瑜,邢廷文,林妩媚,等. 中波红外成像无热化光学系统设计[J]. 应用光学 ,33(1):181-185. BAI Y,XING T W,LIN W M,et al.. Athermalization of middle infrared optical system[J].J. Appl. Opt.,33(1):181-185. (in Chinese) [10] 郜洪云,熊涛,杨长城. 中波红外连续变焦光学系统[J]. 光学精密工程 ,2007,15(7):1038-1043. GAO H Y,XIONG T,YANG CH CH. Middle infrared continuous zoom optical system[J].Opt. Precision Eng.,2007,15(7):1038-1043.(in Chinese) [11] 张明意,李保平,万中南,等. 折-衍混合型两档变倍红外光学系统设计[J]. 红外与工程 ,2008,37(5):850-853. ZHANG M Y,LI B P,WAN ZH M,et al.. Design of the switch-zoom dual-field-of-view infrared optical system with hybrid refractive-diffractive[J].Infrared and Laser Eng.,2008,37(5):850-853.(in Chinese) [12] 杨为锦,孙强. 中波红外连续变焦系统设计[J]. 中国光学与应用光学 ,2010,3(2):164-169. YANG W J,SUN Q. Design of middle infrared continuous zoom system[J].Chinese J. Opt. Appl. Opt.,2010,3(2):164-169.(in Chinese) [13] 赵新亮,王海霞,崔莉,等. 长波双视场扫描型红外光学系统设计[J]. 红外与工程 ,2011,40(8):1517-1520. ZHAO X L,WANG H X,CUI L,et al.. Design of dual-field scanning LWIR optical system[J].Infrared and Laser Eng.,2011,40(8):1517-1520.(in Chinese)
