空间与单模光纤和光子晶体光纤的耦合效率

doi:10.3788/CO.20130602.0208

陈雪坤^1,2,
张璐^1,2,
吴志勇^1,,

1.
中国科学院长春光学精密机械与物理研究所,吉林长春 130033;
2.
中国科学院大学,北京 100049

基金项目:

中科院长春光机所所内创新资助项目(No.Y10532B110)

详细信息

通讯作者:
吴志勇, E-mail:ziluit@163.com

中图分类号:TN25;TN249
计量
- 文章访问数:3447
- HTML全文浏览量:572
- PDF下载量:852
- 被引次数:0
出版历程
- 收稿日期:2012-12-17
- 修回日期:2013-01-23
- 刊出日期:2013-04-10

Coupling efficiency of free-space laser coupling into single mode fiber and photonic crystal fiber

1.
Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China;
2.
University of Chinese Academy of Sciences, Beijing 100049, China

More Information

Corresponding author:WU Zhi-yong

摘要

摘要:为了设计最优光纤耦合系统,利用高斯模场近似单模阶跃光纤的模场和大模面积光子晶体光纤的模场,推导出了理想情况下空间与这两种光纤的耦合效率解析表达式以及光纤端面相对于耦合系统存在横向偏移和端面倾斜时的耦合效率解析表达式。基于上述理论表达式计算了空间与光纤的耦合效率,并通过实验验证了此理论表达式的有效性。理论计算和实验均证实了单模阶跃光纤对于横向偏移更敏感,当横向偏移量等于单模光纤的纤芯半径时所对应的耦合效率只有20.25%,为理论最大值的1/4;而大模面积光子晶体光纤对于端面倾斜更加敏感,当端面倾斜2时对应的耦合效率只有40.5%,为理论最大值的1/2。所提出理论表达式和实验方法完全可以为设计光纤耦合系统提供准确的参数。
- 单模光纤/
- 光子晶体光纤/
- 空间/
- 光纤耦合/
- 耦合效率/
- 横向偏移/
- 端面倾斜
Abstract:It is necessary to confirm the system parameters by theoretical analysis and experiments for designing a optimum fiber-coupling system. By approximating the mode fields of a Single Mode Fiber(SMF) with a step index and a Photonic Crystal Fiber(PCF) with a Large Mode Area(LMA) using the Gaussian mode field, two analytical expressions for fiber-coupling efficiency in an ideal case and in the presences of lateral offset and fiber-end tilt are derived. Based on the two theoretical expressions, the efficiency for free-space laser coupling into the fibers is computed. Moreover, the validity of the two expressions are verified by experiments. As a result, the theoretical computation and experiments demonstrate that the SMF with the step index is more sensitive to the lateral offset compared to the PCF. When the offset is equal to the radius of the fiber core, the efficiency is only 20.25%, which is a quarter of the theoretical maximum efficiency. Besides, the PCF with the LMA is more sensitive to the fiber-end tilt. When the tilt angle is 2, the efficiency is only 40.5%, which is a half of the theoretical maximum efficiency. In conclusion, the proposed theoretical expressions and experiments can provide accurate parameters for designing fiber-coupling systems.
- single mode fiber/
- photonic crystal fiber/
- free-space laser/
- optical fiber coupling/
- coupling efficiency/
- lateral offset/
- end tilt

HTML全文

参考文献 (1)

[1] POLISHUK A,ARNON S. Optimization of a laser satellite communication system with an optical preamplifier[J].J. Opt. Soc. Am. A,2004,21:1307-1315. [2] TOYOSHIMA M,JONO T,NAKAGAWA K,et al.. Optimum divergence angle of a Gaussian beam wave in the presence of random jitter in free-space laser communication systems[J].J. Opt. Soc. Am. A,2002,19:567-571. [3] CHEN C C,GARDNER C S. Impact of random pointing and tracking errors on the design of coherent and incoherent optical intersatellite communication links[J].IEEE Trans. Commun.,1989,37:252-260. [4] ARNON S,ROTMAN S R,KOPEIKA N S. Performance limitations of a free-space optical communication satellite network owing to vibrations:heterodyne detection[J].Appl. Opt.,1998,37:6366-6374. [5] MA J,ZHAO F,TAN L Y,et al.. Plane wave coupling into single-mode fiber in the presence of random angular jitter[J].Appl. Opt.,2009,48(27):5184-5189. [6] TOYOSHIMA M. Maximum fiber coupling efficiency and optimum beam size in the presence of random angular jitter for free-space laser systems and their applications[J].J. Opt. Soc. Am. A,2006,23(9):2246-2250. [7] KNIGHT J C,BIRKS T A,RUSSELL P St J,et al.. All-silica single-mode optical fiber with photonic crystal cladding[J].Opt. Lett.,1996,21(19):1547-1549. [8] LU S,LI W,GUO H,et al.. Analysis of birefringent and dispersive properties of photonic crystal fibers[J].Appl. Opt.,2011,50(30):5798-5802. [9] XI X M. Mode-field expansion in photonic crystal fibers[J].Appl. Opt.,2011,50(25):E50-E54. [10] RUILIER C,CASSAING F. Coupling of large telescope and single-mode waveguides:application to stellar interferometry[J].J. Opt. Soc. Am. A,2001,18(1):143-149. [11] CORBETT J C W,ALLINGTON-SMITH J R. Coupling starlight into single-mode photonic crystal fiber using a field lens[J].Opt. Express,2005,13(17):6527-6540. [12] CORBETT J,DABIRIAN A,BUTTERLEY T,et al.. The coupling performance of photonic crystal fibres in fibre stellar interferometry[J].Mon. Not. R. Astron. Soc.,2006,368:203-210. [13] CORBETT J C W,MORRIS T J,ALLINGTON-SMITH J R. Tip-tilt requirements for coupling starlight into single-mode photonic crystal fibres using a lenslet:a first analysis[J].New Astron. Rev.,2006,49(12):675-680. [14] POPPETT C,ALLINGTON-SMITH J. Coupling efficiency and termination of photonic crystal fibres for astronomy[J].SPIE,2008,7018:7018Y1. [15] VERGNOLE S,DELAGE L,REYNAUD F,et al. Using photonic crystal fibre in the frame of stellar interferometer[J].SPIE,2004,5491:1416-1424. [16] NAHAR N K,ROJAS R G. Coupling loss from free space to large mode area photonic crystal fibers[J].J. Lightwave Technol.,2008,26(22):3669-3676. [17] HIROOKA T,HORI Y,NAKAZAWA M. Gaussian and Sech approximations of mode field profiles in photonic crystal fibers[J].IEEE Photonics Techonol. Lett.,2004,16(4):1071-1073. [18] GOODMAN J W.Introduction to Fourier Optics[M]. New York:McGraw-Hill,1996.
