随机并行梯度下降算法在束整形中的应用

doi:10.3788/CO.20140702.0260

刘磊^1,2,
郭劲^1,,,
赵帅¹,
姜振华¹,
孙涛¹,
王挺峰¹

1.
中国科学院长春光学精密机械与物理研究所与物质相互作用国家重点实验室, 吉林长春 130033;
2.
中国科学院大学, 北京 100049

基金项目:

吉林省重大科技攻关资助项目（No.20126015）

详细信息

作者简介:
刘磊（1989-），男，山东潍坊人，硕士研究生，2011年于中国科学技术大学获得学士学位，主要从事束整形方面的研究。E-mail：lei@mail.ustc.edu.cn

通讯作者:
郭劲，E-mail：guojin1964@126.com

中图分类号:TP301;TN241
计量
- 文章访问数:1354
- HTML全文浏览量:216
- PDF下载量:618
- 被引次数:0
出版历程
- 收稿日期:2013-10-15
- 修回日期:2014-02-17
- 刊出日期:2014-03-25

Application of stochastic parallel gradient descent algorithm in laser beam shaping

1.
State Key Laboratory of Laser Interaction with Matter, Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China;
2.
University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要:为了满足高光束质量要求，校正束在传输过程中产生的波前畸变，改善位相分布，进而提高聚焦光斑的能量集中度，基于79单元微机械薄膜变形镜（MMDM）搭建了一套束整形实验系统。利用随机并行梯度下降（SPGD）算法，分别选择聚焦光斑半径、形心为中心的环围能量比和质心为中心的环围能量比作为算法性能指标，开展了束整形实验研究。3种情况下，分别经过58次、197次、133次迭代趋于收敛，但光斑半径作为性能指标时振荡严重；环围能量比从整形前的0.200 5、0.127 7、0.200 5分别增加到整形后的0.669 9、0.733 9、0.864 0。实验结果表明：MMDM用于束整形具有良好的效果，光斑半径作为性能指标整形速度最快，其次为质心环围能量比，形心环围能量比最慢；质心环围能量比作为性能指标整形效果最好，其次为形心环围能量比，光斑半径最差。综合比较，质心环围能量比作为性能指标时综合效果最好。
- 随机并行梯度下降算法/
- 束整形/
- 微机械薄膜变形镜/
- 性能指标
Abstract:In the field of laser applications, in order to meet the need of high laser beam quality, correct the wave-front aberration generated during the transmission of laser beam and improve the laser phase distribution, thereby increase the energy concentration of the beam focusing spot, a set of laser beam shaping experimental system is built based on a 79-channel micromachine membrane deformable mirror(MMDM). By using stochastic parallel gradient descent(SPGD) algorithm, the laser beam shaping experiment is carried out respectively with three performance indexes:radius of the focused spot, encircled energy ratio with geometric center as the center, and encircled energy ratio with centroid as the center. In the three cases, convergences come forth after about 58 times, 197 times, 133 times of iterations, respectively, but the evolution curve of spot radius oscillates seriously. Encircled energy ratios increase from 0.200 5, 0.127 7, 0.200 5 before shaping to 0.669 9, 0.733 9, 0.864 0 after shaping, respectively. The results of experiments show that MMDM can be used for laser beam shaping with well results. The shaping speed is fastest with spot radius as the performance index, followed by encircled energy ratio of centroid and encircled energy ratio of geometric center. The shaping effect is best with encircled energy ratio of centroid, followed by the encircled energy ratio of geometric center and spot radius. After synthetical comparison, it is best to choose encircled energy ratio of centroid as the performance index.
- stochastic parallel gradient descent(SPGD) algorithm/
- laser beam shaping/
- micromachine membrane deformable mirror(MMDM)/
- performance index

HTML全文

参考文献 (1)

[1] FRIEDEN B R. Lossless conversion of a plane laser wave to a plane wave of uniform irradiance[J].Appl. Opt., 1965, 4(11):1400-1403. [2] SHEALY D L, CHAO S H. Geometric optics-based design of laser beam shapers[J].Opt. Eng., 2003, 42(11):3123-3138. [3] 张振荣, 王晟, 李国华, 等. 平面诱导荧光实验中激励的光束整形[J]. 中国光学, 2013, 6(3):359-364. ZHANG ZH R, WANG SH, LI G H,et al.. Exciting laser beam shaping in planar laser-induced fluorescence experiment[J].Chinese Optics, 2013, 6(3):359-364.(in Chinese) [4] 孟祥翔, 刘伟奇, 柳华, 等. 反射式椭圆高斯光束平顶整形系统[J]. 发光学报, 2013, 34(7):940-947. MENG X X, LIU W Q, LIU H,et al.. A reflective optical system for converting elliptical Gaussian laser beam to flat-top beam[J].Chin. J. Lumin., 2013, 34(7):940-947.(in Chinese) [5] 高瑀含, 安志勇, 李娜娜, 等. 高斯光束整形系统的光学设计[J]. 光学精密工程, 2011, 19(7):1464-1471. GAO Y H, AN ZH Y, LI N N,et al.. Optical design of Gaussian beam shaping[J].Opt. Precision Eng., 2011, 19(7):1464-1471.(in Chinese) [6] 蒋鹏志, 马浩统, 袁凌峰, 等. 基于并行梯度下降算法的自适应任意口径光束整形[J]. 中国 , 2011, 38(12):42-46. JIANG P ZH, MA H T, YUAN L F,et al.. Shaped beam of arbitrary size with adaptive optics based on stochastic parallel gradient descent control algorithm[J].Chinese J. Lasers, 2011, 38(12):42-46.(in Chinese) [7] 王卫兵, 赵帅, 郭劲, 等. 遗传算法在整形中的应用[J]. 与红外, 2012, 42(10):1115-1119. WANG W B, ZHAO SH, GUO J,et al.. Genetic algorithm used in laser shaping[J].Laser Infrared, 2012, 42(10):1115-1119.(in Chinese) [8] YANG P, LIU L, YANG W,et al.. An adaptive laser beam shaping technique based on a genetic algorithm[J].Chinese Optics Letters, 2007, 5(9):497-500. [9] 余湛, 马浩统, 杜少军. 基于模拟退火算法的自适应近场光束整形[J]. 光学学报, 2011, 31(3):0314003-1-5. YU ZH, MA H T, DU SH J. Adaptive near-field beam shaping based on simulated annealing algorithm[J].Acta Optica Sinica, 2011, 31(3):0314003-1-5.(in Chinese) [10] 刘莹, 马剑强, 何挺, 等. 模拟退火-爬山混合算法用于无波前传感器快速像差校正[J]. 光学精密工程, 2012, 20(2):213-219. LIU Y, MA J Q, HE T,et al.. Hybrid simulated annealing-hill climbing algorithm for fast aberration correction without wavefront sensor[J].Opt. Precision Eng., 2012, 20(2):213-219.(in Chinese) [11] 王卫兵, 赵帅, 郭劲, 等. 基于Zernike模式的随机并行梯度下降算法的收敛速率[J]. 中国光学, 2012, 5(4):407-415. WANG W B, ZHAO SH, GUO J,et al.. Convergence rate of stochastic parallel gradient descent algorithm based on Zernike mode[J].Chinese Optics, 2012, 5(4):407-415.(in Chinese) [12] 梁永辉, 王三宏, 龙学军, 等. 随机并行梯度下降光束净化实验研究[J]. 光学学报, 2008, 28(4):613-618. LIANG Y H, WANG S H, LONG X J,et al.. Experimental explorations of the laser beam cleanup system based on stochastic parallel-gradient-descent algorithm[J].Acta Optica Sinica, 2008, 28(4):613-618.(in Chinese) [13] VORONTSOV M A, CARHART G W, RICKLIN J C. Adaptive phase-distortion correction based on parallel gradient-descent optimization[J].Opt. Lett., 1997, 22(12):907-909. 周仁忠.自适应光学[M]. 北京:国防工业出版社, 1996. ZHOU R ZH.Adaptive Optics[M]. Beijing:National Defense Industry Press, 1996.(in Chinese) [15] 晏虎, 雷翔, 刘文劲, 等. 37单元双压电片变形镜板条光束净化[J]. 强与粒子束, 2012, 24(7):1663-1666. YAN H, LEI X, LIU W J,et al.. Beam cleanup of slab laser with 37-element bimorph deformable mirror[J].High Power Laser and Particle Beams, 2012, 24(7):1663-1666.(in Chinese) [16] 林旭东, 薛陈, 刘欣悦, 等. 自适应光学波前校正技术发展现状[J]. 中国光学, 2012, 5(4):337-351. LIN X D, XUE CH, LIU X Y,et al.. Current status and research development of wavefront correctors for adaptive optics[J].Chinese Optics, 2012, 5(4):337-351.(in Chinese) [17] 李邦明. 基于微机械薄膜变形镜的像差校正技术及其应用[D].南京:南京航空航天大学, 2010. LI B M. Technology and application of aberration correction based on micromachined membrane deformable mirror[D]. Nanjing:Graduate School of Nanjing University of Aeronautics and Astronautics, 2010.(in Chinese) [18] 贾建禄, 王建立, 赵金宇, 等. 可扩展式自适应光学系统波前处理器的硬件设计[J]. 液晶与显示, 2011, 26(3):370-373. JIA J L, WANG J L, ZHAO J Y,et al.. Hardware design for extendible adaptive optics system wave-front processor[J].Chinese J. Liquid Crystals and Displays, 2011, 26(3):370-373.(in Chinese) [19] 陈浩, 宣丽, 胡立发, 等. 望远镜的紧凑型闭环液晶自适应光学系统设计[J]. 液晶与显示, 2010, 25(3):379-385. CHEN H, XUAN L, HU L F,et al.. Design on compact type closed-loop liquid crystal adaptive optical system for telescope[J].Chinese J. Liquid Crystals and Displays, 2010, 25(3):379-385.(in Chinese) [20] VORONTSOV M A, CARHART G W, COHEN M,et al.. Adaptive optics based on analog parallel stochastic optimization: analysis and experimental demonstration[J].J. Opt. Soc. Am. A, 2000, 17(8):1440-1453.
