摘要:为了研究不同黄疸治疗仪光源的发光光谱对新生儿产生紫外辐射、热辐射等潜在的光生物安全问题，本文利用光辐射安全测定系统OST-300对传统蓝光荧光灯、普通蓝光LED灯以及经简单遗传算法计算与拟合的蓝光LED灯进行了测试与对比分析。实验结果表明：传统蓝光荧光灯在315，330，365 nm的紫外光处有明显的波峰出现，且峰值波长在365 nm处较为明显；传统蓝光荧光灯在老化后其蓝光光谱光衰严重，且存在大量的红外光线；而基于简单遗传算法计算与拟合的蓝光LED发光光谱与体内胆红素的吸收光谱相吻合，能避免对新生儿的光辐射危害。因此，本文提出的蓝光LED是治疗新生儿黄疸的理想光源。Abstract:In order to research the ultraviolet radiation, thermal radiation and other potential photobiological safety problems in different luminescence spectra of jaundice therapeutic devices, the spectrum of the traditional blue fluorescent lamp, the common blue LED lamp, the blue LED lamp through calculation and fitting by the simple genetic algorithm are tested and compared using the optical radiation safety test system OST-300. Experimental results indicate that, there are three obvious peaks at 315, 330 and 365 nm for the traditional blue fluorescent lamp, and the peak is more obvious at 365 nm; the blue spectrum attenuation of the traditional blue fluorescent lamp after aging is serious, existing a lot of infrared light. The spectrum of the blue light LED based on calculation and fitting by the simple genetic algorithm conforms to the absorption spectrum of bilirubin in vivo. The blue light LED can avoid the optical radiation damage to the neonate, and it is an ideal light source for the neonatal jaundice treatment.
-
图 1不同波长的光对皮肤的穿透能力
Figure 1.Ability of different wavelength of light to penetrate the skin
图 34种样品的发光光谱与体内胆红素吸收光谱
Figure 3.Luminescence spectra of four kinds of samples and absorption spectra of bilirubin in vivo
图 4样品1和样品4在250~400 nm处的紫外光谱
Figure 4.Ultraviolet spectra of sample 1 and sample 4 at 250-400 nm
图 5样品2和衰减后蓝光荧光灯在250~400 nm处的紫外光谱
Figure 5.UV spectra of sample 2 and attenuated blue fluorescent lamp at 250-400 nm
表 1不同光源在18 Lx时的光化学紫外危害与皮肤热危害
Table 1.Ultraviolet chemical hazards and thermal skindamage of different light sources in 18 Lx
危害名称 衰减后的蓝
光荧光灯传统蓝
光荧光灯普通蓝光
LED(S2)特殊蓝
光LEDES/(W·m-2) 2.70×10-5 3.40×10-6 3.10×10-8 2.80×10-5 EH/(W·m-2) 0.480 0.24 0.450 0.150
下载:
导出CSV
表 2不同光源在500 Lx时光化学紫外危害与皮肤热危害
Table 2.Ultraviolet chemical hazards and thermal skindamage of different light sources in 500 Lx
危害名称 传统蓝光
荧光灯普通蓝光
LED(S2)普通蓝光
LED(S3)特殊蓝光
LEDES/(W·m-2) 4.50×10-5 1.80×10-7 1.8×10-5 1.80×10-8 EH/(W·m-2) 4.60 8.40 8.2 2.90 下载:
导出CSV
表 3不同光源在辐照度为200 μW·cm-2时光化学紫外危害与皮肤热危害
Table 3.Ultraviolet chemical hazards and thermalskin damage of different light sources in200 μW·cm-2irradiance
危害名称 传统蓝光
荧光灯普通蓝光
LED(S2)普通蓝光
LED(S3)特殊蓝
光LEDES/(W·m-2) 1.8×10-5 2.1×10-8 3.7×10-10 7.1×10-9 EH/(W·m-2) 3.2 2.7 2.1 2.6 下载:
导出CSV
-
[1] 李俊芳.新生儿黄疸治疗方法新进展[J].当代护士, 2014(1):22-24.http://www.cnki.com.cn/Article/CJFDTOTAL-DDHZ201401013.htmLI J F. New progress in the treatment of neonatal jaundice[J]. Today Nurse, 2014(1):22-24. (in Chinese)http://www.cnki.com.cn/Article/CJFDTOTAL-DDHZ201401013.htm [2] GAN R T, GUO Z N, LIN J B. Spectral matching research for light emitting diode based neonatal jaundice therapeutic device light source[J]. Applied Physics B, 2015, 120(4):645-651.doi:10.1007/s00340-015-6177-y [3] 甘如婷, 郭震宁.新生儿黄疸治疗仪用LED光源光谱功率分布匹配[J].中国光学, 2014, 7(5):794-800.//www.illord.com/CN/abstract/abstract9193.shtmlGAN R T, GUO ZH N. Spectral power distribution matching for light-emitting diode-based neonatal jaundice therapeutic device[J]. Chinese Optics, 2014, 7(5):794-800. (in Chinese)//www.illord.com/CN/abstract/abstract9193.shtml [4] KUMAR P, MURKI S, MALIK G K. Light-emitting diodes versus compact fluorescent tubes for phototherapy in neonatal jaundice:a multi-center randomized controlled trial[J]. Indian Pediatrics, 2010, 47(2):131-137.doi:10.1007/s13312-010-0020-7 [5] MOHAMMADIZADEH M, ELIADARANI F K, BADIEI Z. Is the light-emitting diode a better light source than fluorescent tube for phototherapy of neonatal jaundice in preterm infants?[J]. Advanced Biomedical Research, 2012, 1(3):1-5.https://www.researchgate.net/publication/234159315_Is_the_light-emitting_diode_a_better_light_source_than_fluorescent_tube_for_phototherapy_of_neonatal_jaundice_in_preterm_infants [6] SURMELI-ONAY O, KORKMAZ A, YIGIT S. Phototherapy rash in newborn infants:does it differ between conventional and light emitting diode phototherapy?[J]. Pediatric Dermatology, 2013, 30(5):529-533.doi:10.1111/pde.2013.30.issue-5 [7] 陈斌华. 光生物安全计量标准与测量方法研究[D]. 北京: 北京理工大学, 2015.CHEN B H. Study on the standard and measurement methods of light and biological safety[D]. Beijing:Beijing Institute of Technology, 2015. (in Chinese) [8] 马慧敏. 皮肤光老化机制研究-紫外线照射对成纤维细胞染色体端粒DNA复制的影响[D]. 西安: 第四军医大学, 2009.MA H M. Study on the mechanism of skin photo aging:the effect of ultraviolet irradiation on the chromosome telomere DNA replication in fibroblasts[D]. Xi'an:The Fourth Military Medical University, 2009. (in Chinese) [9] 刘平, 杨荣丽, 苏慧.红外线影响人皮肤成纤维细胞中c-Jun、Ⅰ型和Ⅲ型胶原的表达[J].南方医科大学学报, 2016, 36(2):163-169.http://www.cnki.com.cn/Article/CJFDTOTAL-DYJD201602004.htmLIU P, YANG R L, SU H. Expression of c-Jun, type I and type Ⅲ collagen in human skin fibroblasts[J]. Journal of Southern Medical University, 2016, 36(2):163-169. (in Chinese)http://www.cnki.com.cn/Article/CJFDTOTAL-DYJD201602004.htm [10] KALE Y, AYDEMIR O, CELIK V. Effects of phototherapy using different light sources on oxidant and antioxidant status of neonates with jaundice[J]. Early Human Development, 2013, 89(12):957-960.doi:10.1016/j.earlhumdev.2013.09.013 [11] 冯奇斌, 李亚妮, 李其功, 等.基于发光二极管配光曲线设计自由曲面透镜[J].光学精密工程, 2016, 28(8):1884-1893.http://www.cnki.com.cn/Article/CJFDTOTAL-GXJM201608009.htmFENG Q B, LI Y N, LI Q G, et al.. Design of double freeform surface lens based on LED radition characteristics[J]. Optics and Precision Engineering, 2016, 28(8):1884-1893. (in Chinese)http://www.cnki.com.cn/Article/CJFDTOTAL-GXJM201608009.htm [12] 谈茜, 饶丰, 张永林, 等.由多个高斯函数表征的发光二极管光谱模型[J].中国光学, 2012, 5(5):493-498.//www.illord.com/CN/abstract/abstract8882.shtmlTAN Q, RAO F, ZHANG Y L, et al.. LED spectral model characterized by several Gaussian functions[J]. Chinese Optics, 2012, 5(5):493-498. (in Chinese)//www.illord.com/CN/abstract/abstract8882.shtml [13] 刘智明. 不同光谱能量分布的中波紫外线对皮肤的损伤及其防护策略[D]. 广州: 华南师范大学, 2010.LIU Z M. Ultraviolet spectral energy distribution on the skin damage and protection strategy[D]. Guangzhou:South China Normal University, 2010. (in Chinese) [14] 项红升, 李明, 霍荣龄. LED应用于光疗的研究进展[J].北京生物医学工程, 2005, 24(4):311-325.http://www.cnki.com.cn/Article/CJFDTOTAL-BJSC200504020.htmXIANG H S, LI M, HUO R L. Research progress of LED application in phototherapy[J]. Beijing Biomedical Engineering, 2005, 24(4):311-325. (in Chinese)http://www.cnki.com.cn/Article/CJFDTOTAL-BJSC200504020.htm [15] 陆玲, 徐燕, 上官诚.荧光粉的光衰机理[J].复旦学报(自然科学版), 1987, 26:452.http://www.cnki.com.cn/Article/CJFDTOTAL-FDXB198704063.htmLU L, XU Y, SHANGGUAN C. Attenuation mechanism of fluorescent powder[J]. Journal of Fudan University (Natural Science Edition), 1987, 26:452. (in Chinese)http://www.cnki.com.cn/Article/CJFDTOTAL-FDXB198704063.htm -
