Influence of glucose concentration on blood optical properties in THz frequency range
doi:10.3788/CO.20181102.0182
-
摘要:无创性血糖检测仍是糖尿病患者护理安全舒适的现实科学任务。本文研究了血糖光学特性与血糖浓度之间的相关性。用时域THz光谱研究了全血在0.3~0.5 THz频率范围内的透射谱。在注射胰岛素后的短时间内，由同一糖尿病患者产生了生物样品。得到了血液光学特性的频散特性。基于频散，给出了血糖浓度与折射率和介电常数的关系式。这项工作是复杂研究的一部分，重点是无创葡萄糖测量技术的发展。记录血糖水平与血液光学参数之间的依赖关系，使得将来可以使用反射光谱技术进行无创血糖水平检测。Abstract:Non-invasive blood glucose sensing is still actual scientific task for more safe and comfort diabetes care. This article shows correlation between blood optical properties and its glucose concentration. The transmission spectra of whole blood have been studied by the time-domain THz spectroscopy in the frequency range from 0.3 to 0.5 THz. Biosamples were produced from the same person with the diabetes mellitus during a short time period after the insulin injection have been used. Frequency dispersions of blood optical properties are obtained. Based on frequency dispersions, the dependences of blood glucose concentrations with the refractive index and permittivity are presented. This work is a part of the complex investigation, which focuses on the development of a non-invasive glucose measuring technique. Registering dependences between blood glucose level and blood optical parameters allows for using the reflective spectroscopy techniques in future for non-invasive blood glucose level sensing.
-
Key words:
- spectroscopy/
- terahertz/
- glucose/
- diabetes mellitus
-
Figure 1.Schematic diagram of the setup(FL-1:femtosecond laser based on potassium-yttrium tungstate crystal activated with ytterbium(Yb:KYW), generating femtosecond pulses; F1, 2:a set of teflon filters for IR wavelength range cutting off, BS:beamsplitter, DL:optical delay line, M1, 2, 3:mirrors, Sam:investigated sample, Wol.:Wollaston prism, CdTe:electro optical cadmium-telluric crystal, BD:balanced detector, LA:lock-in amplifier, PC:personal computer, GTP:Glan-Taylor prism, PM1, 2:parabolic mirrors, Ch:chopper, DAC:digital to analog converter, ADC:analog to digital converter
Figure 4.Dispersions of optical parameters of samples with different glucose concentrationcglucose: (a)the real part of refractive indexnreal(f); (b)the absorption coefficientα(f); (c)the real part of permittivityεreal(f); (d)the imaginary part of permittivityεimag(f)
Figure 5.Dependencies of glucose concentration with (a) the real part of refractive indexcglusoseand (b)with the real part of permittivitycglucose(εreal) at different frequencies
Table 1.The list of the glucose concentrations of samples used in experiment
Sample No. mmol/L mg/dL 1 3.0 54.0 2 3.8 68.4 3 6.2 111.6 4 9.2 165.6 5 11.0 198.0 6 14.9 268.2 7 18.0 324.0 8 19.0 342.0
下载:
导出CSV
-
[1] NORTHAM L, BARANOSKI G. A novel first principles approach for the estimation of the sieve factor of blood samples[J].Optics Express, 2010, 18:7456-7469.doi:10.1364/OE.18.007456 [2] REID C B, REESE G, GIBSON A P,et al.. Terahertz time-domain spectroscopy of human blood[J].IEEE Transactions on Terahertz Science and Technology, 2013, 3:363-367.doi:10.1109/TTHZ.2013.2267414 [3] TUCHIN V V.Tissue Optics: Light Scattering Methods and Instruments for Medical Diagnosis[M]. CRC Press, 2015. [4] POPESCU D P, SOWA M G. In vitro assessment of optical properties of blood by applying the extended Huygens-Fresnel principle to time-domain optical coherence tomography signal at 1300 nm[J].Journal of Biomedical Imaging, 2008, 7:591618.http://www.ncbi.nlm.nih.gov/pubmed/18618002 [5] YIM D, BARANOSKI G V, KIMMEL B W,et al.. A cell-based light interaction model for human blood[J].Wiley Online Library, 2012, 31:845-854.http://www.researchgate.net/publication/264618183_A_Cell-Based_Light_Interaction_Model_for_Human_Blood [6] FITZGERALD A, BERRY E, ZINOV'EV N,et al.. Catalogue of human tissue optical properties at terahertz frequencies[J].Journal of Biological Physics, 2003, 29:123-128.doi:10.1023/A:1024428406218 [7] GUSEV S, BOROVKOVA M, STREPITOV M,et al.. Blood optical properties at various glucose level values in THz frequency range[J].European Conferences on Biomedical Optics, 2015:95372A.doi:10.1117/12.2195959.full [8] GUSEV S I, BALBEKIN N, SEDYKH E,et al.. Influence of creatinine and triglycerides concentrations on blood optical properties of diabetics in THz frequency range[J].Journal of Physics:Conference Series, 2016, 735:012088.doi:10.1088/1742-6596/735/1/012088 [9] CERIELLO A, COLAGIURI S. International diabetes federation guideline for management of postmeal glucose:a review of recommendations[J].Diabetic Medicine, 2008, 25:1151-1156.doi:10.1111/dme.2008.25.issue-10 [10] CHERKASOVA O, NAZAROV M, SHKURINOV A. Noninvasive blood glucose monitoring in the terahertz frequency range[J].Optical and Quantum Electronics, 2016, 48:1-12.doi:10.1007/s11082-015-0274-3 [11] CHERKASOVA O, NAZAROV M, BERLOVSKAYA E,et al.. Studying human and animal skin optical properties by terahertz time-domain spectroscopy[J].Bulletin of the Russian Academy of Sciences:Physics, 2016, 80:479-483.doi:10.3103/S1062873816040067 [12] CHERKASOVA O, NAZAROV M, SMIRNOVA I,et al.. Application of time-domain THz spectroscopy for studying blood plasma of rats with experimental diabetes[J].Physics of Wave Phenomena, 2014, 22:185-188.doi:10.3103/S1541308X14030042 [13] SELYATITSKAYA V, PALCHIKOVA N, KUZNETSOVA N,et al.. Adrenocortical system activity at highly and lowly resistant to alloxandiabetogenic action rats[J].Fundamental Research, 2011, 3:142-147.doi:10.3103/S1541308X14030042 [14] SELYATITSKAYA V G, PALCHIKOVA N A, KUZNETSOVA N V. Adrenocortical system activity in alloxan-resistant and alloxan-susceptible wistar rats[J].Journal of Diabetes Mellitus, 2012, 2:165.doi:10.4236/jdm.2012.22026 [15] TSENG T F, YOU B, GAO H C,et al.. Pilot clinical study to investigate the human whole blood spectrum characteristics in the sub-THz region[J].Optics Express, 2015, 23:9440-9451.doi:10.1364/OE.23.009440 [16] JEONG K, HUH Y M, KIM S H,et al.. Characterization of blood using terahertz waves[J].Journal of Biomedical Optics, 2013, 18:107008-107008.doi:10.1117/1.JBO.18.10.107008 [17] ANGELUTS A, BALAKINA V, EVDOKIMOVM G,et al.. Characteristic responses of biological and nanoscale systems in the terahertz frequency range[J].Quantum Electronics, 2014, 44:614.doi:10.1070/QE2014v044n07ABEH015565 [18] LARIN K V, ELEDRISI M S, MOTAMEDI M,et al.. Noninvasive blood glucose monitoring with optical coherence tomography:a pilot study in human subjects[J].Diabetes Care, 2002, 25:2263-2267.doi:10.2337/diacare.25.12.2263 [19] TARR R V. Non-invasive blood glucose measurement system and method using stimulated raman spectroscopy: US, 5243983[P]. 1993-09-14. [20] THOMAS G H. Method and apparatus for non-invasive monitoring of blood glucose. US, 5119819[P]. 1992-06-09 [21] POPOV A P, BYKOV A V, TOPPARI S,et al.. Glucose sensing in flowing blood and intralipid by laser pulse time-of-flight and optical coherence tomography techniques[J].IEEE Journal of Selected Topics in Quantum Electronics, 2012, 18:1335-1342.doi:10.1109/JSTQE.2011.2175202 [22] SMITH J.The Pursuit of Noninvasive Glucose[M]. 5th Edition. [S. l. ]:http://www.mendosa.com/noninvasive-glucose.pdf,2017. [23] SCHELLER M, DVRRSCHMIDT S F, STECHER M,et al.. Terahertz quasi-time-domain spectroscopy imaging[J].Applied Optics, 2011, 50:1884.doi:10.1364/AO.50.001884 [24] BESPALOV V G, GORODETSKIǏ A, DENISYUK I Y,et al.. Methods of generating superbroad band terahertz pulses with femtosecond lasers[J].Journal of Optical Technology, 2008, 5:636-642.http://www.researchgate.net/publication/249336946_Methods_of_generating_superbroadband_terahertz_pulses_with_femtosecond_lasers?ev=auth_pub [25] BESPALOV V G, GORODETSKY A A, GRACHEV Y V,et al.. Influence of THz broadband pulse radiation on some biotissues[J].Proceedings of SPIE, 2009, 7547:754707.doi:10.1117/12.855046 [26] SHEFFIELD C A, KANE M P, BAKST G,et al.. Accuracy and precision of four value-added blood glucose meters:the Abbott Optium, the DDI Prodigy, the HDI True Track, and the HypoGuard Assure Pro[J].Diabetes Technology&Therapeutics, 2009, 11:587-592.https://www.researchgate.net/publication/26822375_Accuracy_and_Precision_of_Four_Value-Added_Blood_Glucose_Meters_the_Abbott_Optium_the_DDI_Prodigy_the_HDI_True_Track_and_the_HypoGuard_Assure_Pro [27] BIESTER T, DANNE T, BLÄSIG S,et al.. Pharmacokinetic and prandial pharmacodynamic properties of insulin degludec/insulin aspart in children, adolescents, and adults with type 1 diabetes[J].Pediatric Diabetes, 2016, 17:642-649.doi:10.1111/pedi.2016.17.issue-8 [28] BOGNER P, SIPOS K, LUDANY A,et al.. Steady-state volumes and metabolism-independent osmotic adaptation in mammalian erythrocytes[J].European Biophysics Journal, 2002, 31:145-152.doi:10.1007/s00249-001-0198-7 [29] JAIN S K. Hyperglycemia can cause membrane lipid peroxidation and osmotic fragility in human red blood cells[J].Journal of Biological Chemistry, 1989, 64:21340-21345.http://www.ncbi.nlm.nih.gov/pubmed/2592379 [30] SON J-H.Prospects in Medical Applications of Terahertz Waves and Conclusions[M].Terahertz Biomedical Science and Technology, CRC Press, 2014: 347-350. -
