摘要:研制了一种新型的PbSe量子点近红外光源，其光致发光谱较窄，能有效匹配气体的红外吸收峰。采用配位溶剂法合成出5.1 nm的PbSe量子点，并将其沉积到GaN芯片上（沉积厚度为165.5 μm），经过紫外光照处理和固化后制成了光致发光的近红外光源。该光源第一激子吸收峰位于1 592 nm，光致发光峰位于1 665 nm，其发射光谱包含了1 625~1 840 nm之间的CH 4气体的全部的吸收谱。利用其进行CH 4气体浓度检测实验，结果表明，系统的检测下限可以达到100×10 -6，检测误差为2%。这种由PbSe量子点近红外光源构成的新型检测系统具有低功耗、低成本和高效能等优点，将其应用在气体检测中时可以略去滤光片，其在红外气体检测领域中有着较广阔的应用前景。Abstract:In this paper, a new type of near-infrared light source of PbSe quantum dots(QDs) is introduced. Its photoluminescence(PL) spectrum is narrow which effectively match the infrared absorption peak of targets gases. The 5.1 nm PbSe quantum dots are synthesized by using the coordination solvent method and deposited on the GaN chip(with a deposition thickness of 165.5 μm), then a photoluminescent near-infrared light source is fabricated after ultraviolet light treatment and curing. The first exciton absorption peak of the light source is located at 1 592 nm, the photoluminescence peak is located at 1 665 nm, and its emission spectrum contains the entire absorption spectrum of CH 4gas between 1 625-1 840 nm. The CH 4gas concentration detection experiment is carried out using this light source. The results show that the lowest detection limit of 100×10 -6and the detection error of 2% can be obtained. The new detection system composed of PbSe quantum dots near-infrared light source has the advantages of low power consumption, low cost and high efficiency. When it is used in gas detection, the filter can be omitted, and it has a broad application prospect in the field of infrared gas detection.
-
Key words:
- CH4gas detection/
- PbSe quantum dots/
- near-infrared luminescence
-
图 25.1 nm PbSe QDs的发光谱和CH4的吸收谱线对比图
Figure 2.Comparison diagram of PL spectra of 5.1 nm PbSe QDs and absorption spectra of CH4
图 5PbSe量子点近红外光源发光强度随偏置电压变化曲线
Figure 5.Curves of light intensity of NIR PbSe QDs light source vesus working bias voltage
图 7PbSe量子点近红外光源经过CH4吸收后的发光谱线
Figure 7.PL spectra of NIR PbSe QDs light source after absorbed by CH4with different concentrations
图 8PbSe QDs的发光谱与H2O和CO2吸收谱线对比图
Figure 8.Comparison diagram of PL spectra of PbSe QDs and absorption lines of H2O and CO2
图 9输出电压相对值随CH4浓度变化拟合曲线
Figure 9.Fitted curve of relative value of output voltage at different CH4concentrations
-
[1] SUN L F, CHOI J J, STACHNIK D,et al.. Bright infrared quantum-dot light-emitting diodes through inter-dot spacing control[J].Nature Nanotechnol, 2012, 7(6):369-373.doi:10.1038/nnano.2012.63 [2] DAI X, ZHANG Z, JIN Y,et al.. Solution-processed, high-performance light-emitting diodes based on quantum dots[J].Nature, 2014, 515(7525):96-99.doi:10.1038/nature13829 [3] MA W, SWISHER S L, EWERS T,et al.. Photovoltaic performance of ultrasmall PbSe quantum dots[J].ACS Nano, 2011, 5(10):8140-8147.doi:10.1021/nn202786g [4] CAI W B, SHIN D W, CHEN K,et al.. Peptide-labeled near-infrared quantum dots for imaging tumor vasculature in living subjects[J].Nano Lett., 2006, 6(4):669-676.doi:10.1021/nl052405t [5] KIM G H, GARCÍA DE ARQUER F P, YOON Y J,et al.. High-efficiency colloidal quantum dot photovoltaics via robustself-assembled monolayers[J].Nano Lett., 2015, 15(11):7691-7696.doi:10.1021/acs.nanolett.5b03677 [6] 李红博, 尹坤.基于量子点的荧光型太阳能聚光器[J].中国光学, 2017, 10(5):555-567.//www.illord.com/CN/abstract/abstract9542.shtmlLI H B, YIN K. Quantum dots based luminescent solar concentrator[J].Chinese Optics, 2017, 10(5):555-567.(in Chinese)//www.illord.com/CN/abstract/abstract9542.shtml [7] 李正顺, 岳圆圆, 张艳霞, 等.丁胺包裹的CdSe量子点敏化的TiO2纳米晶薄膜电子转移机制[J].中国光学, 2015, 8(3):428-438.//www.illord.com/CN/abstract/abstract9280.shtmlLI ZH SH, YUE Y Y, ZHANG Y X,et al.. Electron transfer mechanism of butylamine-capped CdSe quantum dot sensitized nanocrystalline TiO2films[J].Chinese Optics, 2015, 8(3):428-438.(in Chinese)//www.illord.com/CN/abstract/abstract9280.shtml [8] 季洪雷, 周青超, 潘俊, 等.量子点液晶显示背光技术[J].中国光学, 2017, 10(5):666-680.//www.illord.com/CN/abstract/abstract9531.shtmlJI H L, ZHOU Q CH, PAN J,et al.. Advances and prospects in quantum dots based backlights[J].Chinese Optics, 2017, 10(5):666-680.(in Chinese)//www.illord.com/CN/abstract/abstract9531.shtml [9] PENG X G, MANNA L, YANG W D,et al.. Shape control of CdSe nanocrystals[J].Nature, 2000, 404:59-61.doi:10.1038/35003535 [10] HU J T, ODOM T W, LIEBER C M,et al.. Chemistry and physics in one dimension:synthesis and properties of nanowires and nanotubes[J].Acc Chem. Res., 1999, 32(5):435-445.doi:10.1021/ar9700365 [11] YU WW, PENG X G. Formation of high-quality CdS and other Ⅱ-Ⅵ semiconductor nanocrystals in noncoordinating solvents:tunable reactivity of monomers[J].Angew. Chem. Int. Ed., 2002, 41(13):2368-2371.doi:10.1002/(ISSN)1521-3773 [12] ZHANG Y, ICHIHASHI T, LANDREE E,et al.. Heterostructures of single-walled carbon nanotubes and carbide nanorods[J].Science, 1999, 285(5434):1719-722.doi:10.1126/science.285.5434.1719 [13] YAN L, ZHANG Y, ZHANG T Q,et al.. Tunable near-infrared luminescence of PbSe quantum dots for multigas analysis[J]Anal. Chem., 2014, 86(22):11312-11318.doi:10.1021/ac5030478 [14] 邢笑雪, 秦宏伍, 商微微.PbSe量子点荧光匹配气体吸收光谱方法研究[J].光谱学与光谱分析, 2016, 36(11):3588-3591.http://d.old.wanfangdata.com.cn/Periodical/gpxygpfx201611026XING X X, QIN H W, SHANG W W. Research of spectrum matching method for PbSe quantum dots luminescence spectrum and gas absorption spectrum[J].Spectroscopy and Spectral Analysis, 2016, 36(11):3588-3591.(in Chinese)http://d.old.wanfangdata.com.cn/Periodical/gpxygpfx201611026 [15] YU W W, FALKNER J C, SHIH B S,et al.. Preparation and characterization of monodisperse PbSe semiconductor nanocrystals in a noncoordinating solvent[J].Chem. Mater., 2004, 35(43):39-46.https://vdocuments.mx/documents/preparation-and-characterization-of-monodisperse-pbse-semiconductor-nanocrystals.html [16] SONG F, LI G L, SONG N,et al.. Design and implementation of differential mid-infrared carbon monoxide detector[J].Optoelectronics Letters, 2013, 9(5):385-388.doi:10.1007/s11801-013-3108-1 [17] 吕瑞红, 宋楠, 宋芳, 等.基于虚拟信号处理平台的差分式中红外甲烷检测系统[J].光电子 , 2013, 24(7):1350-1356.http://mall.cnki.net/magazine/Article/GDZJ201307021.htmLV R H, SONG N, SONG F,et al.. Differental mid-infrared methane detection system based on virtual signal processing platform[J].Journal of Optoelectronics Laser, 2013, 24(7):1350-1356.(in Chinese)http://mall.cnki.net/magazine/Article/GDZJ201307021.htm [18] 逯丹凤, 李洋, 祁志美.小型水样氨氮自动光学检测装置[J].光学 精密工程, 2014, 22(10):2598-2604.http://www.eope.net/gxjmgc/CN/abstract/abstract15513.shtmlLU D F, LI Y, QI ZH M. Compact colorimetric sensor for automatic detection of ammonia nitrogen in water[J].Opt. Precision Eng., 2014, 22(10):2598-2604.(in Chinese)http://www.eope.net/gxjmgc/CN/abstract/abstract15513.shtml [19] ZHANG Y, WANG F, ZHAO Y,et al.. Experiment research on ellipsoidal structure methane using the absorption characteristics of 3.31μm mid-infrared spectroscopy[J].Infrared Phys. Tech., 2012, 55:353-356.doi:10.1016/j.infrared.2012.02.006 [20] 李亚萍, 张广军, 李庆波, 等.空间双光路红外CO2气体传感器及其测量模型[J].光学 精密工程, 2009, 17(1):14-19.http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gxjmgc200901003LI Y P, ZHANG G J, LI Q B,et al.. Infrared CO2gas sensor based on space double beams and its measurement model[J].Opt. Precision Eng., 2009, 17(1):14-19.(in Chinese)http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gxjmgc200901003 -
