摘要:地基红外经纬仪是测量空间军事和科学目标红外数据的重要手段之一。随着现代武器技术在隐身上方面的快速发展，面源体测量越显重要，而辐射亮度是面源红外作战的关键性指标。因此研究可靠的面积分析方法和辐射亮度计算方法对测试航空目标的隐身性能以及研制面源红外假目标具有重要的意义。本文提出一种简单可靠的面目标的提取方法，并利用该面源提取方法在某 ϕ600 mm口径的红外经纬仪上进行辐射测量，测量数据经大气修正后将与标准亮度值进行比较。实验结果表明，利用本文提出的方法反演的辐射亮度的最大误差为11.38%，均方根误差为7.36%。Abstract:The ground-based infrared theodolite is one of the most important means of measuring infrared data of military and scientific targets in space. With the rapid development of modern weapons technology in stealth, the measurement of surface target is becoming more and more important and the radiation brightness is a key indicator of surface type infrared combat. Therefore, it is of great significance to study area analysis method and radiance calculation method to test the stealth performance of the aviation target and to develop surface type infrared false target. In this paper, a simple and reliable method for extracting surface targets is proposed. By this method, radiation measurement is performed on a 600 mm aperture infrared theodolite. The measured data is compared with the standard brightness value after atmospheric correction. The experimental results show that the maximum error of the radiance inversion is 11.38% and the root mean square error is 7.36%. The experimental results show the effectiveness and reliability of the measurement method.
-
图 2均匀大面源黑体法定标原理图
Figure 2.Calibration schematic of uniform large surface source blackbody
图 3地基红外系统辐射特性测量示意图
Figure 3.Schematic of radiation characteristics measurement for base-ground infrared system
图 4面源目标辐射特性测量原理图
Figure 4.Schematic of radiation characteristic measurement for surface target
表 1定标检测误差
Table 1.Error of calibration detection
黑体温度/℃ 2 000 μs误差/% 3 000 μs误差/% 25 -2.06 -2.01 35 0.83 0.83 45 1.90 1.88 55 1.36 1.37 65 0.66 0.67 75 -0.31 -0.35 85 -1.04 -1.08 95 -1.85 -1.88 均方根误差 1.38 1.39
下载:
导出CSV
表 2面目标的测量结果
Table 2.Measurement results of surface target
积分时间/μs 温度/℃ 标准辐射亮度/(W·m-2·sr-1) 测量辐射亮度/(W·m-2·sr-1) 测量误差/% 2000 50 3.084 6 3.335 2 8.12 60 4.161 5 4.635 0 11.38 70 5.520 9 5.969 9 8.13 80 7.212 4 7.506 5 4.08 90 9.289 8 9.344 4 0.59 100 11.810 4 11.372 5 -3.71 110 14.835 1 14.223 4 -4.12 3000 50 3.084 6 3.095 8 0.36 60 4.161 5 4.352 6 4.59 70 5.520 9 5.824 2 5.49 80 7.212 4 7.277 4 0.90 90 9.289 8 9.132 4 -1.69 100 11.810 4 11.142 3 -5.66 110 14.835 1 13.636 1 -8.08 下载:
导出CSV
-
[1] 杨词银, 张建萍, 曹立华.基于实时标校的目标红外辐射测量新方法[J].红外与毫米波学报, 2011, 30(3):284-288.http://d.old.wanfangdata.com.cn/Periodical/hwyhmb201103022YANG C Y, ZHANG J P, CAO L H. Infrared radiation measurement based on real-time correction[J].Infrared Millim. Wave, 2011, 30(3):284-288.(in Chinese)http://d.old.wanfangdata.com.cn/Periodical/hwyhmb201103022 [2] 李波.红外隐身技术的应用及发展趋势[J].中国光学, 2013, 6(6):818-823.//www.illord.com/CN/abstract/abstract9083.shtmlLI B. Application and development trend of infrared stealth technology[J].Chinese Optics, 2013, 6(6):818-823.(in Chinese)//www.illord.com/CN/abstract/abstract9083.shtml [3] 张晓龙, 刘英, 孙强.高精度非制冷长波红外热像仪的辐射定标[J].中国光学, 2012, 5(3):235-241.doi:10.3969/j.issn.2095-1531.2012.03.007ZHANG X L, LIU Y, SUN Q. Radiometric calibration of uncooled long-wave infrared thermal imager with high-precision[J].Chinese Optics, 2012, 5(3):235-241.(in Chinese)doi:10.3969/j.issn.2095-1531.2012.03.007 [4] 李宁, 张云峰, 刘春香, 等.1 m口径红外测量系统的辐射定标[J].光学精密工程, 2014, 22(8):2054-2060.http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gxjmgc201408011LI N, ZHANG Y F, LIU CH X,et al.. Calibration of 1 m aperture infrared theodolite[J].Opt. Precision Eng., 2014, 22(8):2054-2060.(in Chinese)http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gxjmgc201408011 [5] SUN Z Y, CHANG S T, ZHU W. Radiometric calibration method for large aperture infrared system with broad dynamic range[J].Applied Optics, 2015, 54(15):4659-4666.doi:10.1364/AO.54.004659 [6] 张晓龙, 刘英, 王健, 等.不同非均匀性校正温度的红外测温技术[J].中国光学, 2014, 7(1):150-155.//www.illord.com/CN/abstract/abstract9109.shtmlZHANG X L, LIU Y, WANG J,et al.. Infrared thermometry technology with different nonuniformity correction temperatures[J].Chinese Optics, 2014, 7(1):150-155.(in Chinese)//www.illord.com/CN/abstract/abstract9109.shtml [7] 常松涛.红外经纬仪结构设计及提高其辐射测量精度的关键技术研究[D].北京: 中国科学院大学, 2015.CHANG S T. Research on infrared theodolite design and key technologies to improve the radiometry precision[D]. Beijing: University of the Chinese Academy of Sciences, 2015.(in Chinese) [8] 曹立华, 李宁, 杨词银, 等.3~5μm红外探测器的辐射定标[J].红外与 工程, 2012, 41(4):858-864.doi:10.3969/j.issn.1007-2276.2012.04.006CAO L Y, LI N, YANG C Y,et al.. Radiation calibration for 3~5μm infrared detector[J].Infrared and Laser Engineering, 2012, 41(4):858-864.(in Chinese)doi:10.3969/j.issn.1007-2276.2012.04.006 [9] 罗茂捷, 周金梅, 傅景能, 等.考虑积分时间变量的红外系统辐射响应定标[J].红外与 工程, 2013, 42(1):36-40.doi:10.3969/j.issn.1007-2276.2013.01.007LUO M J, ZHOU J M, FU J N,et al.. Integration time as variable for radiometric calibration of infrared system[J].Infrared and Laser Engineering, 2013, 42(1):36-40.(in Chinese)doi:10.3969/j.issn.1007-2276.2013.01.007 [10] 孙志远, 常松涛, 朱玮, 等.应用内外定标修正实现红外测量系统辐射定标[J].光学精密工程, 2015, 23(2):356-362.http://d.old.wanfangdata.com.cn/Periodical/gxjmgc201502006SUN ZH Y, CHANG S T, ZHU W,et al.. Radiation calibration of infrared system by amendment of inner and outer calibration[J].Opt. Precision Eng., 2015, 23(2):356-362.(in Chinese)http://d.old.wanfangdata.com.cn/Periodical/gxjmgc201502006 [11] 杨词银, 张建萍, 曹立华.基于大气透过率比例校正的目标辐射测量[J].光学精密工程, 2012, 20(7):1626-1635.http://d.old.wanfangdata.com.cn/Periodical/gxjmgc201207029YANG C Y, ZHANG J P, CAO L H. Infrared radiation measurement based on proportional corrected atmospheric transmittance[J].Opt. Precision Eng., 2012, 20(7):1626-1635.(in Chinese)http://d.old.wanfangdata.com.cn/Periodical/gxjmgc201207029 [12] 杨词银, 曹立华.大口径红外光电系统辐射定标及误差分析[J].红外与 工程, 2014, 40(9):1624-1628.http://d.old.wanfangdata.com.cn/Periodical/hwyjggc201109005YANG C Y, CAO L H.Radiation calibration and error analysis for a large-aperture infrared opto-electric system[J].Infrared and Laser Engineering, 2014, 40(9):1624-1628.(in Chinese)http://d.old.wanfangdata.com.cn/Periodical/hwyjggc201109005 [13] 孙志远, 王旻, 常松涛.环境温度对红外辐射测量精度的影响及修正[J]. 与红外, 2014, 44(5):522-527.doi:10.3969/j.issn.1001-5078.2014.05.010SUN ZH Y, WANG M, CHANG S T. Effect and correction of environmental temperature on infrared radiation measurement precision[J].Laser&Infrared, 2014, 44(5):522-527.(in Chinese)doi:10.3969/j.issn.1001-5078.2014.05.010 [14] 孙志远.基于中波红外探测器的常温目标测温实验研究[D].长春: 中国科学院长春光学精密机械与物理研究所, 2008.SUN ZH Y. Experimental research of temperature measurement on the target in normal temperature based on MWIR detector[D]. Changchun: Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Science, 2008.(in Chinese) [15] 李周, 乔彦峰, 常松涛, 等.宽动态范围红外辐射测量系统快速定标算法[J].红外与 工程, 2017, 46(5):0617003.http://d.old.wanfangdata.com.cn/Periodical/hwyjggc201706025LI ZH, QIAO Y F, CHANG S T. High-speed calibration and non-uniformity correction for wide dynamic range infrared radiometric system[J].Infrared and Laser Engineering, 2017, 46(5):0617003.(in Chinese)http://d.old.wanfangdata.com.cn/Periodical/hwyjggc201706025 -
