摘要:目前，利用氧化锌（ZnO）微纳米线结构形成具有自然谐振腔的紫外 器件引起国内外广泛关注。针对ZnO本征缺陷导致器件发光及稳定性不足等问题，开展金属局域等离子激元局域场发光增强方面的研究，对ZnO基紫外 器件的应用具有十分重要的意义。本文通过理论仿真构建氧化锌微米线结构模型，对微腔光学损耗及Fabry-Perot（F-P）谐振腔模式演化进行了理论分析。得到ZnO微腔直径变化与F-P谐振模式演化、光学损耗和光强分布的关系。在此基础上通过金属Ag纳米颗粒对ZnO微米线6个表面进行修饰，发现金属局域表面等离子激元共振耦合效应对微腔周围的损耗光有明显的抑制作用，并且在金属与微腔的交叉区通过共振耦合效应实现局域场增强。模拟结果表明，在损耗较大的微腔表面修饰Ag纳米颗粒以后，光场限域能力提高6.72%，而在金属颗粒之间沿 X轴方向产生二次耦合现象，其电场强度更有2倍的增强效果。
-
关键词:
- F-P谐振腔/
- 金属局域表面等离子激元/
- 光学损耗/
- 局域场增强
Abstract:At present, the use of zinc oxide(ZnO) micro-nanowire structures in ultraviolet laser devices with natural resonant cavities has attracted wide attention at home and abroad. Aiming at the problems of the luminescence and stability caused by ZnO intrinsic defects, research on the local field luminescence enhancement of plasmons is very important for the application of ZnO-based UV laser devices. In this paper, ZnO micro-wire structure model is constructed by theoretical simulation and the micro-cavity optical loss and Fabry-Perot(F-P) resonant cavity mode evolution are theoretically analyzed. The relationship between the diameter change of ZnO microcavity and the evolution of the F-P resonance mode, optical loss and light intensity distribution is obtained. On this basis, the six surfaces of ZnO microwires are modified by metal Ag nanoparticles. It is found that the resonance coupling effect of metal local surface plasmons significantly inhibited the loss of light around the microcavity and the local field enhancement is realized by the resonance coupling effect at the intersection of the metal and the microcavity. The simulation results show that after the surface of the microcavity is modified with Ag nanoparticles, the confinement ability of the optical field increased by 6.72%, while the secondary coupling occurs along the X axis between the metal particles, and the electric field intensity is enhanced by 2 times. -
图 1(a) 类F-P 腔结构示意图；(b) 在ZnO微腔中传播的示意图
Figure 1.(a)Structure diagram of an F-P laser cavity; (b)schematic diagram of laser propagation in ZnO microcavity
图 2(a) 局域表面等离子激元振荡图；(b)传播表面等离子激元图
Figure 2.(a)Localized surface plasmon oscillations; (b)spread surface plasmon
图 3不同直径时的(x,y)，(x,z)面电场分布图
Figure 3.The electric field distributions of (x,y), (x,z) planes of the ZnO micro-wires with different diameters
图 4(a) 不同腔径对应的光强曲线；(b)随腔径变化的光限制效率图
Figure 4.(a)Light intensity curves corresponding to different cavity diameters; (b)light-confinement efficiency varies with cavity diameter
图 5不同直径时的ZnO F-P 腔共振谱图
Figure 5.ZnO F-P laser resonant spectra with different diameters
图 6Ag纳米颗粒修饰的LSPR微腔的模拟示意图和对应电场分布
Figure 6.Simulation diagram of LSPR microcavity modified by Ag nanoparticles and corresponding electric field distributions
图 7Ag纳米颗粒修饰微腔的电场强度分布图
Figure 7.Distribution of the electric field intensity of the Ag nanoparticle modified microcavity
图 8Ag纳米颗粒装饰ZnO微米线的局部电场图
Figure 8.Local electric field diagrams of Ag nanoparticle modified ZnO microwire
图 9(a) 随装饰面数目变化的光强曲线；(b)随装饰面数目变化的光限制效率图
Figure 9.(a)Light intensity curve as a function of the number of decorative surface; (b)light confinement efficiency map as a function of the number of decorative surfaces
-
[1] HUANG M H, MAO S, FEICK H,et al.. Room-temperature ultraviolet nanowire nanolasers[J].Science, 2001, 292(5523):1897-1899.doi:10.1126/science.1060367 [2] 申德振, 梅增霞, 梁会力, 等.氧化锌基材料、异质结构及光电器件[J].发光学报, 2014, 35(1):1-60.http://d.old.wanfangdata.com.cn/Periodical/fgxb201401001SHEN D ZH, MEI Z X, LIANG H L,et al.. ZnO-based matierial, heterojunction and photoelctronic device[J].Chinese Journal of Luminescence, 2014, 35(1):1-60.(in Chinese)http://d.old.wanfangdata.com.cn/Periodical/fgxb201401001 [3] 陈国炜, 朱荣.基于氧化锌纳米线的硅谐振式加速度计(英文)[J].光学 精密工程, 2009, 17(6):1279-1285.doi:10.3321/j.issn:1004-924X.2009.06.014CHEN G W, ZHU R. Silicon micromachined resonant accelerometer based on ZnO nanowire[J].Opt. Precision Eng., 2009, 17(6):1279-1285.(in Chinese)doi:10.3321/j.issn:1004-924X.2009.06.014 [4] VASILYEV N, NOVIKOV B V, AKOPYAN I K,et al.. ZnO-based random lasing on nanoparticles realized by laser induced breakdown[J].Journal of Luminescence, 2017, 182:45-48.doi:10.1016/j.jlumin.2016.10.012 [5] RIGHINI G C, BERNESCHI S, COSCI A,et al.. Advanced Sensing by WGM Microresonators[C]. Proceedings of Optical Sensors 2017, Optical Society of America, 2017: SeM2E.5. [6] 王马华, 朱光平, 朱汉清, 等.氧化锌纳米棒中自发辐射的回音壁模腔增强[J].中国 , 2012, 39(7):154-159.http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgjg201207027WANG M H, ZHU G P, ZHU H Q,et al.. Enhancement for spontaneous emission from ZnO hexagonal microrods based on whispering gallery mode resonators[J].Chinese Journal of Lasers, 2012, 39(7):154-159.(in Chinese)http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgjg201207027 [7] DONG H X, ZHOU B E, LI J ZH,et al.. Ultraviolet lasing behavior in ZnO optical microcavities[J].Journal of Materiomics, 2017, 3(4):255-266.doi:10.1016/j.jmat.2017.06.001 [8] MAIER S A.Plasmonics:Fundamentals and Applications[M]. New York:Springer, 2007. [9] YAN R X, GARGAS D, YANG P D. Nanowire photonics[J].Nature Photonics, 2009, 3(10):569-576.doi:10.1038/nphoton.2009.184 [10] WANG Y Y, QIN F F, LU J F,et al.. Plasmon enhancement for Vernier coupled single-mode lasing from ZnO/Pt hybrid microcavities[J].Nano Research, 2017, 10(10):3447-3456.doi:10.1007/s12274-017-1556-9 [11] LONG H, GU J H, WANG H N,et al.. Numerical study of enhanced performance in ZnO-based ultraviolet light-emitting diodes with step graded-composition MgZnO multiple quantum barriers[J].Superlattices&Microstructures, 2017, 190:821-828.http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=45b2494a29659941c24f5c77437fadb3 [12] CHEN T, XING G Z, ZHANG Z,et al.. Tailoring the photoluminescence of ZnO nanowires using Au nanoparticles[J].Nanotechnology, 2008, 19(43):435711.doi:10.1088/0957-4484/19/43/435711 [13] CHENG P H, LI D SH, YUAN ZH ZH,et al.. Enhancement of ZnO light emission via coupling with localized surface plasmon of Ag island film[J].Applied Physics Letters, 2008, 92(4):041119.doi:10.1063/1.2839404 [14] 于旭东, 雷雯, 刘畅.随机振动下光学谐振腔腔体形变及变动规律[J].光学 精密工程, 2017, 25(2):281-288.http://d.old.wanfangdata.com.cn/Periodical/gxjmgc201702001YU X D, LEI W, LIU CH. Deformation law of optical resonant cavity under random vibration environment[J].Opt. Precision Eng., 2017, 25(2):281-288.(in Chinese)http://d.old.wanfangdata.com.cn/Periodical/gxjmgc201702001 [15] 周炳琨, 高以智, 陈家骅, 等. 原理[M].北京:国防工业出版社, 2004:20-76.ZHOU B K, GAO Y ZH, CHEN J H,et al..Laser Principle[M]. Beijing:The National Defense Press, 2004:20-76.(in Chinese) [16] 赫光生, 王润文, 王明常. 物理学[M].上海:上海人民出版社, 1975:95-140.HAO G SH, WANG R W, WANG M CH.Laser Physics[M]. Shanghai:Shanghai People′s Press, 1975:95-140.(in Chinese) [17] 邹英华, 孙碧亨. 物理学[M].北京:北京大学出版社, 1991:68-75.ZHOU Y H, SUN B H.Laser Physics[M]. Beijing:Beijing University Press, 1991:68-75.(in Chinese) [18] 任升, 刘丽炜, 李金华, 等.纳米尺度下的局域场增强研究进展[J].中国光学, 2018, 11(1):31-46.//www.illord.com/CN/abstract/abstract9558.shtmlREN SH, LIU L W, LI J H,et al.. Advances in the local field enhancement at nanoscale[J].Chinese Optics, 2018, 11(1):31-46.(in Chinese)//www.illord.com/CN/abstract/abstract9558.shtml [19] CAO R X, ZHANG X P, MIAO B F,et al.. From self-assembly to quantum guiding:a review of magnetic atomic structures on noble metal surfaces[J].Chinese Physics B, 2014, 23(3):038102.doi:10.1088/1674-1056/23/3/038102 [20] 王雪飞, 卢振武, 王泰升, 等.超表面上表面等离激元波的光栅衍射行为研究[J].中国光学, 2018, 11(1): 60-73.//www.illord.com/CN/abstract/abstract9534.shtmlWANG X F, LU ZH W, WANG T SH,et al.. Grating diffractive behavior of surface plasmon wave on meta-surface[J].Chinese Optics, 2018, 11(1):60-73.(in Chinese)//www.illord.com/CN/abstract/abstract9534.shtml [21] GARGAS D J, TOIMIL-MOLARES M E, YANG P D. Imaging single ZnO vertical nanowire laser cavities using UV-laser scanning confocal microscopy[J].Journal of the American Chemical Society, 2009, 131(6):2125-2127.doi:10.1021/ja8092339 [22] KIM J, KIM S, BAHL G. Complete linear optical isolation at the microscale with ultralow loss[J].Scientific Reports, 2017, 7:1647.doi:10.1038/s41598-017-01494-w [23] WANG Y Y, XU C X, JIANG M M,et al.. Lasing mode regulation and single-mode realization in ZnO whispering gallery microcavities by the Vernier effect[J].Nanoscale, 2016, 8(37):16631-16639.doi:10.1039/C6NR04943E [24] 贾博仑, 邓玲玲, 陈若曦, 等.利用Ag@SiO2纳米粒子等离子体共振增强发光二极管辐射功率的数值研究[J].物理学报, 2017, 66(23):237801.doi:10.7498/aps.66.237801JIA B L, DENG L L, CHEN R X,et al.. Numerical research of emission properties of localized surface plasmon resonance enhanced light-emitting diodes based on Ag@SiO2nanoparticles[J].Acta Physica Sinica, 2017, 66(23):237801.(in Chinese)doi:10.7498/aps.66.237801 [25] SINGH S K, SINGHAL R. Thermal-induced SPR tuning of Ag-ZnO nanocomposite thin film for plasmonic applications[J].Applied Surface Science, 2018, 439:919-926.doi:10.1016/j.apsusc.2018.01.112 -
