红外双波段滤光膜的研制

1.
长春理工大学光电工程学院,吉林长春 130022;
2.
新美亚科技(深圳)有限公司,广东深圳 518038

详细信息

作者简介:
宫大为(1985— ),男,吉林四平人,硕士研究生,主要从事光学薄膜技术方面的研究。 E-mail:gongkenannan@sina.com 付秀华(1963—),女,山东滨州人,教授,主要从事光学薄膜技术及半导体器制造工艺方面的研究。 E-mail:goptics@126.com
宫大为(1985— ),男,吉林四平人,硕士研究生,主要从事光学薄膜技术方面的研究。 E-mail:gongkenannan@sina.com 付秀华(1963—),女,山东滨州人,教授,主要从事光学薄膜技术及半导体器制造工艺方面的研究。 E-mail:goptics@126.com

中图分类号:O484.1
计量
- 文章访问数:4632
- HTML全文浏览量:512
- PDF下载量:1496
- 被引次数:0
出版历程
- 收稿日期:2011-02-21
- 修回日期:2011-04-23
- 刊出日期:2011-06-25

Design and manufacture of infrared double waveband laser filter films

1.
Changchun University of Science and Technology,Changchun 130022,China;
2.
Sanmina-SCI Optical Technology(Shenzhen) Co.,Ltd.,Shenzhen 518038,China

摘要

摘要:为了满足红外军用仪器的特殊要求,根据薄膜理论进行了红外双波段滤光膜的膜系设计;采用电子束真空镀膜的方法,通过对工艺参数的调整,在多光谱ZnS基底上镀制了1 064 nm高反、3~5 m高透的红外双波段滤光膜。利用低能离子轰击,使膜层与基底间的应力明显减小;使用BGS 6341薄膜应力测试仪,采用渐变梯度法,测得其压应力由122 MPa降到51 MPa。另外,通过低能离子轰击和真空退火处理,提高了膜层的抗损伤阈值。结果显示所镀膜层满足红外军用仪器的使用要求。
- 光学薄膜/
- 滤光膜/
- 离子轰击/
- 真空退火
Abstract:In order to meet the special requirements of infrared military equipment, an infrared double waveband filter film system was designed according to the theory of thin film and an infrared dual-band filter membrane with a high reflection at 1 064 nm and a high antireflection in 3~5 m was produced on a multi-spectral ZnS substrate by adjusting process parameters and using electron beam vacuum deposition. With ion bombardment of low energy and vacuum annealing, the anti-damage threshold of thin film was improved. Furthermore, the stress between the film layer and the substrate was reduced to 51 MPa from 122 MPa measured by the BGS 6341 stress tester with gradient method. This film meets the requirements of infrared military equipment.
- optical thin film/
- laser filter membrane/
- ion bombardment/
- vacuum annealing

HTML全文

参考文献 (1)

[1] 李隆,董武威,史彭,等. 二极管阵列侧泵浦Nd:YAG板条的热效应[J]. 光学精密工程 ,2008,16(11):2120-2126. LI L,DONE W W,SHI P,et al.. Thermal effect of diode bar side-pumped Nd:YAG slab[J].Opt. Precision Eng.,2008,16(11):2120-2126.(in Chinese) [2] MACLEOD H A.Thin-film Optical Filters[M]. 3rd ed. Philadelphia:Institute of Physics Publishing,2001. [3] 刘汉英,刘春明,肖志斌,等. 空间太阳电池用光学薄膜[J]. 光学仪器 ,2006,28(4):164-167. LIU H Y,LIU CH M,XIAO ZH B,et al.. Optical thin films for space solar cells[J].Opt. Instruments, 2006,28(4):164-167.(in Chinese) [4] 付秀华,董连和,付新华,等. 红外增透与保护膜技术的研究[J]. 与红外 ,2006,36(12):1162-1164. FU X H,DONG L H,FU X H,et al.. Study of infrared AR and protecting coating technology[J].Laser Infrared,2006, 36(12):1162-1164.(in Chinese) [5] 付秀华,姜会林,付新华,等. 多波段红外增透与保护膜技术的研究[J]. 兵工学报 ,2007,28(10):1183-1185. FU X H,JIANG H L,FU X H,et al.. Study of multi-waveband infrared antireflection and protection film[J].Acta Armamentarii,2007,28(10):1183-1185.(in Chinese) [6] KENNEDY M,RISTAU D,NIEDERWALD H S. Ion beam-assisted deposition of MgF₂and YbF₃films[J].Thin Solid Films,1998,333:191-195. [7] ZHANG CH,WANG Y T,LU W Q. Single-wavelength monitoring method for optical thin-film coating[J].Opt. Eng.,2004,43(6):1439-1444. [8] MACLEOD H A. Optical thin film coating design[J].SPIE,1996,2776:1-8. [9] SHEEHAN L M,KOZLOWSKI M R,RAINER F,et al.. Large-area conditioning of optics for high-power laser systems[J].SPIE,1994,2114:559-568. [10] 潘奕捷,林家明,商庆坤,等. 光学低通滤波器的频率特性和光谱特性[J]. 光学技术 ,2005,31(4):513-515. PAN Y J,LIN J M,SHANG Q K,et al.. Frequency and spectrum characteristic of the optical low pass filter[J].Opt. Technol.,2005,31(4):513-515.(in Chinese)
