船载光电经纬仪坞外星体标校

马庆坤^1,2,
乔彦峰¹

1.
中国科学院长春光学精密机械与物理研究所,吉林长春 130033;
2.
中国科学院研究生院,北京 100039

基金项目:

粤港关键领域重点突破项目(No.2004A10403021);广东省攻关项目(No.2006A10401006);国防科技预研基金资助项目(No.104-0603)

详细信息

作者简介:
马庆坤(1981—),男,河南沈丘人,硕士研究生,主要从事实时控制软件和虚拟仪器软件方面的研究。 E-mail:markingkun@163.com 乔彦峰(1962—),男,吉林长春人,研究员,主要从事光电测量、光电瞄准、光电测控技术方面的研究。 E-mail:qiaoyf@ciomp.ac.cn
马庆坤(1981—),男,河南沈丘人,硕士研究生,主要从事实时控制软件和虚拟仪器软件方面的研究。 E-mail:markingkun@163.com 乔彦峰(1962—),男,吉林长春人,研究员,主要从事光电测量、光电瞄准、光电测控技术方面的研究。 E-mail:qiaoyf@ciomp.ac.cn

中图分类号:V556.5; TP391.4
计量
- 文章访问数:4188
- HTML全文浏览量:460
- PDF下载量:1689
- 被引次数:0
出版历程
- 收稿日期:2010-06-21
- 修回日期:2010-10-13
- 刊出日期:2010-12-20

Offshore star calibration of electro-optical shipborne theodolite

MA Qing-kun^1,2,
QIAO Yan-feng¹

1.
Changchun Institute of Optics,Fine Mechanics and Physics, Chinese Academy of Sciences,Changchun 130033,China;
2.
Graduate University of Chinese Academy of Sciences,Beijing 100039,China

摘要

摘要:为了适应海上应用并降低经纬仪坞内标校成本,采用恒星位置代替固定方位标,将原本在坞内的标校工作转移到海上。首先,根据恒星星表精确、实时地计算出恒星位置。然后,通过坐标转换算法将其位置值转化到测量系下,运用船摇自稳定算法保证经纬仪的正常跟踪并记录数据。最后,根据事后解算算法分析记录数据,分离设备单项差并计算系统误差。实验结果表明,海上星校单项差的标定与坞内通过方位标标定结果非常接近,照准差、水平差、垂直差的偏差分别为0.015、0.22和0.014,系统误差的标定与坞内结果具有很好的一致性,完全能够满足经纬仪海上标校的要求。
- 光电经纬仪/
- 坞外恒星标校/
- 解算
Abstract:In order to meet the requirements of offshore calibration for theodolites and to reduce calibration costs, this paper presents a calibration method of shipborne theodolites. Using this method, almost all the work can be carried out at sea. At first, based on FK5 ephemeris, the apparent position of a star can be calculated in real-time. After the coordinate transition, bootstrap values in the measurement system are ready. The algorithm of ship movement is used to keep the stablization of tracking at sea. At the same time, real-time data are acquired and recorded, and the axis errors and system errors of the theodolite can be calculated based on several algorithms. Experimental results indicate that the precisions of the calibration in dry-dock and the star calibration are very close. The tolerances of visual axis error, horizontal axis error and the vertical axis error are 0.015, 0.22 and 0.014, respectively. The star calibration agrees with the former results very well in system errors after calculations. It can satisfy the requirements of offshore calibrating of a ship-based theodolite.
- theodolite/
- offshore star calibration/
- calculation

HTML全文

参考文献 (1)

[1] 蔡建军,朱杰,周朝猛,等. 船载遥测设备海上动态标校方法[J]. 中国科技信息 ,2006(6):139-140. CAI J J,ZHU J,ZHOU CH M,et al. A theory of dynamic calibration of shipborne telemetering equipments[J].China Sci. Technol. Information,2006(6):139-140.(in Chinese) [2] 金光. 光电经纬仪的自动化标校与白天测星技术研究[J]. 光学精密工程 ,1991(2):87-90. JIN G. A technical study of the automation demarcation and correction and the day light steller measurement for electro-optical tracking systems[J].Opt. Precision Eng.,1991(2):87-90.(in Chinese) [3] 孙晓昶,皇甫堪. 以恒星位置为基准的运动平台上测控雷达精度标校技术[J]. 宇航学报 ,2002,23(3):29-33. SUN X C,HUANG F K. Precision calibration of moving platform based radar with stars as reference marks[J].J. Astronautics,2002,23(3):29-33.(in Chinese) [4] 李艳平,李岩,郭立红,等. 对经纬仪静态精度检测中星校技术误差源的分析[J]. 光学精密工程 ,2004,12(2):79-83. LI Y P,LI Y,GUO L H,et al. Error analysis of star calibration technique in theodolite static presision detection[J].Opt. Precision Eng.,2004,12(2):79-83.(in Chinese) [5] 姚兆宁,孙晓昶. 舰载精密测量雷达星体标校方法及应用[J]. 现代雷达 ,1999,21(4):7-12,31. YAO ZH N,SUN X C. Shipborne accurate instrumentation radar star checkout method and application[J].Modern Radar,1999,21(4):7-12,31.(in Chinese) [6] 刘云飞. 船载测控系统的标校[J]. 无线电通信技术 ,2003,29(2):1-3. LIU Y F. Calibration of ship-based measurement and control system[J].Radio Communications Technol.,2003,29(2):1-3.(in Chinese) [7] 袁诚宏,朱晓峰,陈健,等. 基于联合放球的船载雷达角度零值标校方法[J]. 飞行器测控学报 ,2009,28(4):23-25. YUAN C H,ZHU X F,CHEN J,et al. Balloon-tracking zero angle calibration method for ship-borne radars[J].J. Spacecraft TT&C Technol.,2009,28(4):23-25.(in Chinese) [8] 王琦,张继旭. 基于CCD 经纬仪的雷达标校及数据处理方法[J]. 战术导弹技术 ,2009(1):89-92. WANG Q,ZHANG J X. A method of radar calibration and data processing based on CCD laser theodolite[J].Tactical Missile Technol.,2009(1):89-92.(in Chinese)
