空间光学遥感器热设计

1.
中国科学院长春光学精密机械与物理研究所,吉林长春 130033;
2.
三一重机有限公司,江苏昆山 215300

详细信息

作者简介:
杨献伟(1983—),男,河南安阳人,硕士,主要从事空间光学遥感器热设计及热分析方面的研究。 E-mail:yangxianwei521@163.com

中图分类号:TP73; V445.8
计量
- 文章访问数:4552
- HTML全文浏览量:456
- PDF下载量:1497
- 被引次数:0
出版历程
- 收稿日期:2010-10-12
- 修回日期:2011-12-13
- 刊出日期:2011-04-25

Thermal design of space optical remote sensor

1.
Changchun Institute of Optics,Fine Mechanics and Physics, Chinese Academy of Sciences,Changchun 130033,China;
2.
Sany Heavy Machinery Co.,Led.,Kunshan 215300,China

摘要

摘要:为了保证空间光学遥感器所需温度条件,本着被动热控为主、主动热控为辅的原则对其进行了热设计。首先,分析了遥感器在轨工作模式,建立了遥感器外热流计算模型,根据遥感器各面外热流变化,确定了3个极端工况。然后,以对日低温工况热设计为主对遥感器进行了热设计。最后,对热设计进行了热仿真分析和热试验验证。结果表明:镜组温度水平可控制在(181.5) ℃,且满足轴向温差要求;CCD器件温度变化为18~26 ℃,相邻轨道无温度累加。该热控设计方案可行,可对其它低能量、大窗口空间光学遥感器的热设计提供借鉴。
- 光学遥感器/
- 热设计/
- 热仿真/
- CCD
Abstract:In order to maintain the temperature of a space optical remote sensor in orbit, a thermal control system was designed according to a thermal control strategy that was based on the passive thermal control and aided with the active thermal control. Firstly, based on the work patterns of the space optical remote sensor, a modal for its flux calculation was established. Three extreme conditions were confirmed after analysis on the thermal flux and temperature boundary conditions of the sensor. Then, thermal design was concentrated on the sun-oriented work pattern in a low-temperature condition primarily. Finally, the thermal simulation and thermal test for thermal control system were performed. Simulation and test results show that the temperature fluctuations of mirrors are at (181.5) ℃ and the axis temperature difference meets the requirements of the optical system. The temperature of CCD device can be controlled between 18 ℃ and 26 ℃. The results demonstrate that the thermal design is feasible and these experiments can provide a reference for the thermal design of other optical remote sensors with low energies and big optical windows.
- optical remote sensor/
- thermal design/
- thermal simulation/
- CCD

HTML全文

参考文献 (1)

[1] 闵桂荣,郭舜.航天器热控制[M]. 北京:科学出版社,1998. MIN G R,GUO SH.Spacecraft Thermal Control[M]. Beijing:Science Press,1998.(in Chinese) [2] 訾克明,吴清文,李泽学,等. 空间光学遥感器的热设计实例及其仿真分析[J]. 计算机仿真 ,2008,25(12):77-80. ZI K M,WU Q W,LI Z X,et al.. Simulation analysis of a space optical remote-sensor's thermal design[J].Computer Simulation,2008,25(12):77-78.(in Chinese) [3] 巩盾. 温度对遥感器光学系统成像质量的影响 . 长春:中国科学院长春光学精密机械与物理研究所 ,2010. GONG D. The thermal effect on image quality of the remote sensor optical system .Changchun:Changchun Institute of Optics,Fine Mechanics and Physics,Chinese Academy of Sciences,2010.(in Chinese) [4] 卢锷,颜昌翔,吴清文,等. 空间光学遥感器环境适应性设计与试验研究[J]. 中国光学与应用光学 ,2009,2(5):364-376. LU E,YAN CH X,WU Q W,et al.. Research on adaptability of optical remote sensors in mechanical and space thermal environments[J].Chinese J.Opt. and Appl. Opt.,2009,2(5):364-376.(in Chinese) [5] 黎明,吴清文,江帆,等. 三线阵立体测绘相机热控系统的设计[J]. 光学精密工程 ,2010,18(6):1367-1373. LI M,WU Q W,JIANG F,et al.. Design of thermal control system for three-linear array mapping cameras[J].Opt. Precision Eng.,2010,18(6):1367-1373.(in Chinese) [6] 訾克明,吴清文,郭疆,等. 空间光学遥感器CCD焦平面组件热设计[J]. 光学技术 ,2008,34(3):401-403. ZI K M,WU Q W,GUO J,et al.. Thermal design of CCD focal plane assembly of space optical remote-sensor[J].Opt. Technique,2008,34(3):401-403.(in Chinese) [7] 吴清文,卢泽生,卢锷,等. 空间光学遥感器热分析[J]. 光学精密工程 ,2002,10(2):205-208. WU Q W,LU Z S,LU E,et al.. Thermal analysis for a space optical remote sensor[J].Opt. Precision Eng.,2002,10(2):205-208.(in Chinese) [8] 闵桂荣.卫星热控制技术[M]. 北京:宇航出版社,1991. MIN G R.Satellite Thermal Control Technique[M]. Beijing:Astronautic Publishing House,1991.(in Chinese). [9] 越小虎,沈志刚,王忠涛,等. 一种空间用抗原子氧复合膜β布的原子氧、温度、紫外辐射效应的试验研究[J]. 宇航学报 ,2001,22(3):87-91. ZHAO X H,SHEN ZH G,WANG ZH T,et al.. Experimental investigations of atomic oxygen,temperature,ultraviolet radiation effects in an AO-resistant spacecraft composite material-Beta cloth[J].Chinese J. Aeronautics,2001,22(3):87-91.(in Chinese) [10] 越小虎,沈志刚,王鑫,等. 玻璃纤维复合材料的原子氧剥蚀效应试验研究[J]. 宇航学报 ,2006,27(6):1347-1348. ZHAO X H,SHEN ZH G,WANG X,et al.. An experimental study of atomic oxygen efects on glass fiber composites[J].J. Astronautics,2006,27(6):1347-1348.(in Chinese)
