Comparison of frequency locking of 780 nm diode laser via rubidium saturated absorption and polarization spectroscopies
-
摘要:将 频率锁定于合适的参考频率,可以有效地抑制 器的频率起伏。本文采用铷原子D2线超精细跃迁线的饱和吸收光谱和偏振光谱分别获得鉴频曲线,通过电子伺服系统将频率校正信号负反馈到780 nm光栅外腔反馈半导体 器外腔的压电陶瓷上的方法对 器进行稳频。介绍了两种方法的基本原理和实验方案。与 器自由运转300 s时 器典型的频率起伏约6.6 MHz相比,采用饱和吸收光谱和偏振光谱进行稳频,运转300 s时 器典型的残余频率起伏分别约为1.5 MHz和0.6 MHz。分析表明,饱和吸收光谱稳频采用了相敏检波技术,需要对 器进行频率调制,带来了额外的频率噪声,而偏振光谱稳频则是一种完全无频率调制的稳频方案。Abstract:Locking laser frequency to an available reference standard can efficiently suppress the fluctuation of laser frequency and improve the frequency stability. In this paper, the Saturated Absorption Spectroscopy(SAS) and the Polarization Spectroscopy(PS) of rubidium D2 line were used to obtain the frequency discrimination curves. Then the error correcting signals from the frequency discrimination were sent in negatively feedback to the piezeo-electric transducer of a 780 nm external-cavity diode laser(ECDL) by electronic servo-system to realize the laser frequency locking. The basical principles and experimental schemes of two methods were introduced and the experimental results were compared. It shows that the residual fluctuations of laser frequency after being locked by using the two schemes are approximately 1.5 MHz and 0.6 MHz, respectively, compared with that of about 6.6 MHz for the case of ECDL free running. Furthermore, the PS scheme shows better frequency stability than SAS scheme, for SAS brings extra frequency noise by use of the phase sensitive detection which needs to modulate the laser frequency, while PS scheme is completely modulation-free.
-
[1] 周炳琨,高以智,陈倜嵘,等. 原理[M].5版. 北京:国防工业出版社,2008. ZHOU B K,GAO Y ZH,CHEN T R,et al.. Principle of Lasers[M]. 5th ed. Beijing:National Defense Industry Press,2008.(in Chinese) [2] WIEMAN C,HANCH T W. Doppler-free laser polarization spectroscopy[J].Phys. Rev. Lett.,1976,36(20):1170-1173 [3] YOSHIKAWA Y,UMEKI T,MUKAE T,et al.. Frequency stabilization of a laser diode with use of light-induced birefringence in an atomic vapor[J].Appl. Opt.,2003,42(33):6645-6649. [4] PEARMAN C P,ADAMS C S,COX S G,et al.. Polarization spectroscopy of a closed atomic transition:applications to laser frequency locking[J].J. Phys. B:At. Mol. Opt. Phys.,2002,35(24):5141-5151. [5] 王婧,杨保东,何军,等. 采用偏振光谱对外腔半导体 器稳频时反馈环路带宽的影响[J]. 光学学报 ,2009,29(2):425-430. WANG J,YANG B D,HE J,et al.. Influence of the bandwidth of feedback loop in frequency stabilization of external-cavity diode laser by polarization spectroscopy[J].Acta Optica Sinica,2009,29(2):425-430.(in Chinese) [6] 武寄洲,韩强,马杰,等. 可调平衡探测 偏振光谱研究[J]. 光学学报 ,2009,29(9):2601-2606. WU J ZH,HAN Q,MA J,et al.. Research on the adjustable balance probe for laser polarization spectroscopy[J].Acta Optica Sinica,2009,29(9):2601-2606.(in Chinese) [7] 马杰,赵延霆,赵建明,等. 利用偏振光谱对外腔式半导体 器实现无调制锁频[J]. 中国 ,2005,32(12):1605-1608. MA J,ZHAO Y T,ZHAO J M,et al.. Frequency stabilization of an external cavity diode laser using polarization spectroscopy without frequency modulation[J].Chinese J. Laser,2005,32(12):1605-1608.(in Chinese) [8] FOOT C J.Atomic Physics[M]. New York:Oxford University Press,2005. -
