大相对孔径红外消热差物镜设计

张鑫,
贾宏光

中国科学院长春光学精密机械与物理研究所,吉林长春 130033

基金项目:

国防科技创新重要方向项目(No.YYYJ-1122)

详细信息

中图分类号:TN216
计量
- 文章访问数:4396
- HTML全文浏览量:497
- PDF下载量:1350
- 被引次数:0
出版历程
- 收稿日期:2011-04-16
- 修回日期:2011-07-17
- 刊出日期:2011-08-25

Optical design of infrared athermalized objective with large relative aperture

Changchun Institute of Optics,Fine Mechanics and Physics, Chinese Academy of Sciences,Changchun 130033,China

摘要

摘要:研究了大相对孔径光学系统的设计方法,讨论了光学设计初始的光焦度分配计算,设计了F数为0.9的大相对孔径红外消热差物镜。建立了由多个光组构成的组合光学系统的消热差模型,结合光学系统的结构型式和所选择的光学材料组合,获得了初始的光焦度分配,利用计算机辅助优化设计完成了像差校正。环境温度分析表明,在-40~60 ℃,该物镜成像质量稳定,调制传递函数(MTF)接近衍射极限。实际设计结果与理论计算结果相符合。
- 光学设计/
- 红外光学系统/
- 消热差设计/
- 大相对孔径
Abstract:A design method for the optical system with a large relative aperture was researched and the initial optical power distribution of optical lenses was discussed. A F/0.9 infrared athermalized objective with a large relative aperture was proposed. Firstly, an athermal design model for the multiple-lens composed optical system was established. Then, by considering the systematic structure form and the selected optical materials, the initial optical power distribution among the lenses was accomplished. Finally, the aberration of the design was corrected by computer aid optimization design. The analysis of environment temperature shows that the image quality of the objective is stable in the change of temperature from 40 ℃ to 60 ℃ and its Modulation Transfer Function(MTF) approximates to the diffraction limit. The result of the implemented design agrees well with that of the theoretic computation.
- optical design/
- infrared optical system/
- athermalized design/
- large relative aperture

HTML全文

参考文献 (1)

[1] 杨为锦,孙强. 中波红外连续变焦系统设计[J]. 中国光学与应用光学 ,2010,3(2):164-169. YANG W J,SUN Q. Design of middle infrared continuous zoom system[J].Chinese J. Opt. Appl. Opt.,2010,3(2):164-169.(in Chinese) [2] 张红鑫,卢振武,孙强,等. 折/衍混合长波红外凝视成像系统的杂散光分析[J]. 中国光学与应用光学 ,2009,2(5):402-407. ZHANG H X,LU ZH W,SUN Q,et al.. Stray light analysis of diffractive/refractive LWIR string imaging system[J].Chinese J. Opt. Appl. Opt.,2009,2(5):402-407.(in Chinese) [3] TAMAGAWA Y,WAKABAYASHI S,TAJIME T,et al.. Multilens system design with an athermal chart[J].Appl. Opt.,1994, 33 (34):8009-8013. [4] TAMAGAWA Y,TAJIME T. Expansion of an athermal chart into a multilens system with thick lens spaced apart[J].Opt. Eng.,1996,35(10):3001-3006. [5] 胡玉禧,周绍祥,相里斌,等. 消热差光学系统设计[J]. 光学学报 ,2000,20(10):1386-1391. HU Y X,ZHOU SH X,XIANG L B,et al.. Design of athermal optical system[J].Acta Opt. Sinica,2000,20(10):1386-1391.(in Chinese) [6] 杨新军,王肇圻,母国光,等. 红外双波段消热差系统设计[J]. 光电子· ,2004,15(4):385-389. YANG X J,WANG ZH Q,MU G G,et al.. Design of infrared dual-band athermal optical system[J].J. Optoelectronics·Laser,2004,15(4):385-389.(in Chinese) [7] 王学新,焦明印. 红外光学系统无热化设计方法的研究[J]. 应用光学 ,2009,30(1):129-133. WANG X X ,JIAO M Y. Athermalization design for infrared optical systems[J].J. Appl. Opt.,2009,30(1):129-133.(in Chinese) [8] 张铁楠,王肇圻,孙强. 折/衍射混合红外物镜的超宽温消热差设计[J]. 中国 ,2005,32(3):311-314. ZHANG T N,WANG ZH Q,SUN Q. Athermalized design of extensive temperature range for infrared hybrid refractive-diffractive objective[J].Chinese J. Lasers,2005,32(3):311-314.(in Chinese) [9] 陈杰,白剑,杨国光,等. 基于谐衍射特性的双波段红外系统消热差设计[J]. 光学仪器 ,2006,28(3):61-65. CHEN J,BAI J,YANG G G,et al.. Design of athermalization for dual-band infrared optical system based on harmanic diffraction[J].Opt. Instruments,2006,28(3):61-65.(in Chinese) [10] 宋岩峰,邵晓鹏,徐军. 实现复消色差的超常温混合红外光学系统[J]. 物理学报 ,2008,57(10):6298-6303. SONG Y F,SHAO X P,XU J. Design of a hybrid infrared apochromatic optical system beyond normal temperature[J].Acta Phys. Sinica,2008,57(10):6298-6303.(in Chinese) [11] 孙金霞、刘建卓、孙强,等. 折/衍射混合消热差共形光学系统的设计[J]. 光学精密工程 ,2010,18(4):792-797. SUN J X,LIU J ZH,SUN Q,et al.. Athermal design for hybrid refractive/diffractive comformal optical system[J].Opt. Precision Eng.,2010,18(4):792-797.(in Chinese) [12] 陈潇,杨建峰,马小龙,等. 8~12 μm折-衍混合物镜超宽温度消热差设计[J]. 光学学报 ,2010,30(7):2090-2092. CHEN X,YANG J F,MA X L,et al.. Athermalization design of wide temperature range for hybrid efractive-diffractive objective in 8~12 μm[J].Acta Opt. Sinica,2010,30(7):2090-2092.(in Chinese)
