驾束制导仪中调制盘的设计

李娜^1,2,
王红¹

1.
中国科学院长春光学精密机械与物理研究所,中国科学院光学系统先进制造技术重点实验室,吉林长春 130033;
2.
中国科学院研究生院,北京100039

详细信息

中图分类号:TJ765; TH745
计量
- 文章访问数:4153
- HTML全文浏览量:547
- PDF下载量:1264
- 被引次数:0
出版历程
- 收稿日期:2011-05-21
- 修回日期:2011-07-23
- 刊出日期:2011-08-25

Design of modulation disk for laser-beam riding guided sighting instrument

LI Na^1,2,
WANG Hong¹

1.
Key Laboratory of Optical System Advanced Manufacturing Technology,Changchun Institute of Optics,Fine Mechanics and Physics,Chinese Academy of Sciences,Changchun 130033,China;
2.
Graduate University of Chinese Academy of Sciences,Beijing 100039,China

摘要

摘要:介绍了驾束制导仪中调制盘的空间编码原理,阐述了调制盘的设计过程,采用单调制盘来缩小驾束制导仪的体积和重量。考虑到制导仪器实际工作的各种因素,设计了调制盘内、外码道的宽度,起止位置和5种频率值。给出了调制盘确定偏航信息的原理,表征导弹位置信息的调制系数和频率的计算方法。针对调制盘两场交接处的误码问题,提出了变角度设计方法,将各频率沿径向方向旋转45,从而保证了5 ms的场周期,提高了制导精度。
- 驾束制导仪/
- 调制盘/
- 变角度
Abstract:The spatial encoding principle of the modulation disk in a laser-beam riding guided sighting instrument is introduced. The design procedure of the modulation disk is described, and a single disk is selected to reduce the volume and weight of the guided sighting instrument. By considering every influencing factor of guided sighting instrument, the width, start-stop positions of inner and outer code paths and five kinds of frequencies are designed. The principle of defining deviation information, modulation coefficient characterizing the position information of a missile and the method of computing frequency are given. To avoid error codes of two fields' alternation, the design method to change angles is presented to rotate every frequency pattern 45 along the radial of the modulation disk. Experiments show that the method ensures the field cycle of 5 ms, and improve the guided precision.
- laser-beam riding guided sighting instrument/
- modulation disk/
- changing angle

HTML全文

参考文献 (1)

[1] 江月松,钟宇,李亮. 某型号瞄准制导仪中的调制盘图案的设计[J]. 光学技术 ,2005,31(1):73-76. JIANG Y S,ZHONG Y,LI L. Design of patterns of modulation disk in a certain modal of guided sight instrument[J].Opt. Technique,2005,31(1):73-76.(in Chinese) [2] 江月松,钟宇,李亮. 瞄准制导仪中的调制盘光学系统分析[J]. 光学技术 ,2005,31(2):200-201. JIANG Y S,ZHONG Y,LI L. Analysis of optical system of modulation disk in a certain modal of guided sight instrument[J].Opt. Technique,2005,31(2):200-201.(in Chinese) [3] 钱义先,程小薇,张剑家,等. 驾束制导系统编码调制技术的研究 . 长春:长春理工大学 ,2006. QIAN Y X,CHENG X W,ZHANG J J,et al.. Research of encoding and modulating technology on laser beam-riding guidance .Changchun:Changchun University Science and Technology,2006.(in Chinese) [4] 苗瑞生,刘藻珍.反坦克炮射导弹研究分析报告汇编 . 北京:北京理工大学,1995. MIAO R SH,LIU Z ZH.Antitank Gun-delivered Missile Research Report Assembly. Beijing:Beijing institute of science and technology,1995.(in Chinese) [5] 杨宜禾,岳敏,周维真.红外系统[M]. 2版.北京:国防工业出版社,1995. YANG Y H,YUE M,ZHOU W ZH.Infrared System[M]. 2nd ed. Beijing:National Defense Industry Press,1995.(in Chinese) [6] 徐南荣,卞南华.红外辐射与制导[M]. 北京:国防工业出版社,1999. XU N R,BIAN N H.Infrared Radiation and Homing[M]. Beijing:National Defense Industry Press,1995.(in Chinese) [7] 马利国,伍波,周鼎富,等. 10.6 μm 驾束制导仪编码调制器设计[J]. 红外与工程 ,2010,39(1):71-75. MA L G,WU B,ZHOU D F,et al.. Design of the code modulator on 10.6 μm laser beam-riding guidance instrument[J].Infrared and Laser Eng.,2010,39(1):71-75. (in Chinese)
