摘要:本文设计了一套加工装置，对氧化锆陶瓷板 切割的熔化物颗粒进行收集，并采用Imagine-Pro Pluse（IPP）图像处理软件对熔化物颗粒的形态（数量、形状、平均直径、标准差及其分布情况）进行研究。通过气熔比控制方法，对板厚分别为0.8mm、1mm、1.5mm、3mm的氧化锆陶瓷板进行 切割实验。实验结果表明：不同板厚参数下，球形熔化物颗粒所占百分比范围从99.21%降到89.81%，圆饼形从0.79%升至7.44%，哑铃形从0升至2.75%。随着板厚的增加，圆饼形和哑铃形颗粒所占百分比增大，球形颗粒所占百分比降低，球形颗粒平均直径和标准差随之增大，切面粗糙度由2.287μm增加到5.946μm。建立了熔化物去除几何模型，阐述了熔化物颗粒与切割质量的关系，球形颗粒所占的百分比越大，平均直径和标准差越小，切割质量越好，最终获得质量较高切割样件。Abstract:A set of processing device is designed to collect the melt particles during laser cutting zirconia ceramic. The melt particles morphology including quantity, shape, mean dimeter, standard deviation, and distribution are studied using the image processing software of Imagine-Pro Pluse(IPP). Various cutting experiments with different ceramic thicknesses(0.8mm, 1.0mm, 1.5mm and 3mm) are taken based on controlling of vapor-to-melt ratio. Results of IPP observation show that, with the ceramic thickness increased, the percentage of spherical molten particles is declined from 99.21% to 89.81%, while the cakey and dumbbell shaped molten particles are ascended from 0.79% to 7.44% and 0 to 2.75% respectively, and the mean and standard deviation of spherical melt particles diameter also are enlarged. Simultaneously, with the increasing of mean and standard deviation of spherical particle diameter, the roughness of kerf surface is deteriorated from 2.287μm to 5.946μm. The establishment of geometric model reveals the connection between the form of removal molten particles and cutting quality. The larger the percentage of spherical molten particles, the smaller the mean diameter and standard deviation, and then the better the cutting quality. The high quality cutting sheet is achieved finally.
-
Key words:
- laser cutting/
- zirconia ceramic/
- molten particles/
- image processing
-
图 5板厚对各形状熔化物颗粒所占百分比的影响
Figure 5.Effect of thickness on percentage of different melt particles
图 6板厚对球形颗粒平均直径和标准差的影响
Figure 6.Effect of thickness on average diameter of particles and standard
图 9球形熔化物颗粒平均直径对切面粗糙度的影响
Figure 9.Effect of mean spherical melt particles diameter on roughness of kerf surface
表 1(3Y-TZP)氧化锆陶瓷化学成分(质量分数，%)
Table 1.Composition of (3Y-TZP) Zirconia Ceramic (mass fraction, %)
ZrO2 Y2O3 SiO2 TiO2 Na2O Fe2O3 Others 94.8 5.1 0.030 0.030 0.005 0.007 0.030
下载:
导出CSV
表 2(3Y-TZP)氧化锆陶瓷热物理参数
Table 2.Heat physical parameters of (3Y-TZP)Zirconia Ceramic
热物理参数 数值 氧化锆含量/% 94.8 吸收率/% ＞90 热传导率/(W/m·K) 2.5 热膨胀系数(10-6/℃) 10.0 熔点/℃ 2 550 密度/(g·cm-3) 6.05 下载:
导出CSV
表 3 切割工艺参数
Table 3.Parameters of laser cutting
参数 数值 频率/Hz 30 离焦量/mm 0 脉冲宽度/ms 2 辅助吹气压力/MPa 0.8 下载:
导出CSV
表 4不同板厚及不同工艺参数下的气熔比值
Table 4.Vapor-melt ratios at different thickness and cutting parameters
试验序号 1 2 3 4 板厚/mm 0.8 1 1.5 3 功率/W 75 75 75 75 切割速度/(mm·min-1) 120 120 120 120 气熔比 0.209 0.192 0.160 0.086 下载:
导出CSV
表 5不同板厚下不同形状颗粒个数
Table 5.Number of different shape particles at different thicknesses
板厚/mm 0.8 1 1.5 3 颗粒总数 383 396 359 363 球形颗粒个数 380 389 341 326 圆饼形颗粒个数 3 7 16 27 哑铃形颗粒个数 0 0 2 10 下载:
导出CSV
-
