摘要:为了分析 合束光学系统的成像质量，本文研究了 合束光学系统的热耦合效应。借助光学设计软件建立 合束系统模型，基于传热学理论，根据光学系统结构及流场条件参数建立气体流体模型。根据光线追迹法编写用户自定义函数，通过数值模拟定量研究了介质气体热效应引起的波像差系数。仿真分析了气体热效应在不同时间下对 合束光学系统的影响。结果表明，受重力影响 合束系统热效应的旋转对称性变得不再明显，随着温度升高呈现分层变化，且非均匀热效应以低阶像差为主。将波像差系数导入光学设计软件，可实现复杂光场与热场耦合传函的定量分析，波像差劣化0.3 λ，传递函数下降0.1。Abstract:The thermal coupling effecting on laser beam combining optical system is studied in this paper in order to analyze the imaging quality of the system. The laser beam combining system is modeled using optical design software, and the gas fluid model is established based on heat transfer theory according to the structure of the optical system and the parameters of the flow field. According to the ray tracing method, a user-defined function is defined and the wave aberration coefficient caused by the thermal effect of the medium gas is quantitatively studied through numerical simulation. The influence of gas thermal effect on the laser optical system at different time is simulated and analyzed. The results show that the rotational symmetry of the thermal effect in the beam combination system is no longer noticeable under the influence of gravity, but stratification changes with increasing temperature, and the non-uniform thermal effect is dominated by low-order aberrations. The wave aberration coefficient can be imported into the optical design software to quantitatively analyze the transfer function of the coupling of the complex optical field and the thermal field. At this time, the wave aberration is deteriorated by 0.3 λ, and the transfer function value is decreased by 0.1.
-
图 2不同位置处光学系统出瞳波相差
Figure 2.Wavefront map at exit pupil of optical system in different position
图 45 s条件下气体相位分布(a)和泽尼克系数(b)
Figure 4.Phase distribution(a) and Zernike coefficient(b) under radiation for 5 s
图 560 s条件下气体相位分布(a)及泽尼克系数(b)
Figure 5.Phase distribution(a) and Zernike coefficient(b) under radiation for 60 s
表 1标准状态下介质气体参数
Table 1.Parameters of gas medium in standard state
Parameters Value Densityρ/(kg·m-3) 1.250 6 Thermal conductivityλ/[W/(m·K)] 0.026 Thermal expansivityαT/[1/K] 0.003 356 CapacityCp/[J/(kg·K)] 1 040.67 Refractive indexn0 1.000 279 3 Thermal refractive index coefficientnT/[1/K] -0.929×10-6 Absorption coefficientα/[1/m] 1×10-5[6]
下载:
导出CSV
表 2光学结构及流场条件参数
Table 2.Parameters of optical structure and fluid field
Parameters Value Single channel heat fluxQ/[w/m2] 200 Operating pressureP0/Pa 101 325 Entrance pupil diameterD/mm 800 Single channel EPDDsingle/mm 200 Optical path differenceOPD/mm 1 000 Gravity accelerationg/[m/s2] 9.8 Wavelengthλ/nm 1 060 下载:
导出CSV
表 3光学传递函数(60 lp/mm)
Table 3.Optical Diffraction MTF(60 lp/mm)
Position 1 Position 2 Position 3 Position 4 Position 5 Position 6 0 s Focus Position 0.412 0.407 0.407 0.407 0.407 0.412 5 s Focus Position 0.411 0.405 0.391 0.410 0.402 0.398 60 s Focus Position 0.410 0.339 0.359 0.349 0.375 0.286 下载:
导出CSV
-
[1] 张巍, 于新峰, 周连生, 等.精密光学系统的热像差[J].光学精密工程, 2015, 23(11):3033-3040.http://kns.cnki.net/KCMS/detail/detail.aspx?filename=gxjm201511005&dbname=CJFD&dbcode=CJFQZHANG W, YU X F, ZHOU L SH, et al.. Thermal aberration in precision optical system[J]. Opt. Precision Eng., 2015, 23(11):3033-3040.(in Chinese)http://kns.cnki.net/KCMS/detail/detail.aspx?filename=gxjm201511005&dbname=CJFD&dbcode=CJFQ [2] BREAUX H, EVERS W, SEPUCHA R, et al.. Algebraic model for cw thermal-blooming effects[J]. Applied Optics, 1979, 18(15):2638-2644.http://www.ncbi.nlm.nih.gov/pubmed/20212723 [3] LADERMAN A J. Thermal blooming in axial pipe flow:comment[J]. Applied Optics, 1980, 19(14):2269-2270.doi:10.1364/AO.19.002269 [4] STEPHENS T, JOHNSON D C, LANGUIRAND M T. Beam path conditioning for high-power laser system[J]. The Lincoln Laboratory Journal, 1900, 3(2):225-244.http://www.researchgate.net/publication/258986470_Beam_path_conditioning_for_high-power_laser_systems [5] 金钢, 刘顺发, 李树民, 等. 热效应对光束控制系统发射光束质量的影响[J].中国 , 2002, A29(10):895-899.doi:10.3321/j.issn:0258-7025.2002.10.009JIN G, LIU SH F, LI SH M, et al.. Laser thermal effects in beam control system on the emitted laser quality[J]. Chinese J. Lasers, 2002, A29(10):895-899.(in Chinese)doi:10.3321/j.issn:0258-7025.2002.10.009 [6] 季小玲, 陶向阳, 吕百达. 非均匀性和内光路热效应对远场特性的影响[J].中国 , 2004, 31(10):1193-1197.doi:10.3321/j.issn:0258-7025.2004.10.010JI X L, TAO X Y, LV B D. Influence of laser nonuniformity and thermal effects in an inner optical system on the far-field behavior[J]. Chinese J. Lasers, 2004, 31(10):1193-1197.(in Chinese)doi:10.3321/j.issn:0258-7025.2004.10.010 [7] 孙运强, 习锋杰, 许晓军, 等.内通道流场与光场能量耦合的数值模拟[J].中国 , 2011, 38(2):020213.http://www.opticsjournal.net/abstract.htm?id=OJ1312240000866B9EaHSUN Y Q, XI F J, XU X J, et al.. Model for the optical field and fluent field coupling effects[J]. Chinese J. Lasers, 2011, 38(2):020213.(in Chinese)http://www.opticsjournal.net/abstract.htm?id=OJ1312240000866B9EaH [8] 胡鹏, 苏华, 安建祝, 等.封闭管道中热耦合效应对 传输的影响[J].强 与粒子束, 2013, 25(7):1651-1656.http://kns.cnki.net/KCMS/detail/detail.aspx?filename=qjgy201307014&dbname=CJFD&dbcode=CJFQHU P, SU H, AN J ZH, et al. Thermal coupling effects on laser propagation in closed tube[J]. High Power Laser and Particle Beams, 2013, 25(7):1651-1656.(in Chinese)http://kns.cnki.net/KCMS/detail/detail.aspx?filename=qjgy201307014&dbname=CJFD&dbcode=CJFQ [9] 孙毅, 高云国, 邵帅.高功率热效应对合束系统的影响[J].光学精密工程, 2015, 23(1):3097-3106.http://kns.cnki.net/KCMS/detail/detail.aspx?filename=gxjm201511013&dbname=CJFD&dbcode=CJFQSUN Y, GAO Y G, SHAO SH. Influence of high power laser thermal effect on beam combination system[J]. Opt. Precision Eng., 2015, 23(11):3097-3106.(in Chinese)http://kns.cnki.net/KCMS/detail/detail.aspx?filename=gxjm201511013&dbname=CJFD&dbcode=CJFQ [10] 聂山钧, 郭劲, 邵俊峰, 等. 辐照下镀铬介质高吸收镜的热变形[J].中国光学, 2015, 8(1):84-90.//www.illord.com/CN/abstract/abstract9216.shtmlNIE SH J, GUO J, SHAO J F, et al.. Thermal deformation of high absorption chrome plated mirror irradiated by laser[J]. Chinese Optics, 2015, 8(1):84-90.(in Chinese)//www.illord.com/CN/abstract/abstract9216.shtml [11] 安海霞, 邓坤, 闭治跃.高功率 装备小型化轻量化技术[J].中国光学, 2017, 10(3):321-330.//www.illord.com/CN/abstract/abstract9477.shtmlAN H X, DENG K, BI ZH Y. Miniaturization and lightweight technology of high-power laser equipment[J]. Chinese Optics, 2017, 10(3):321-330.(in Chinese)//www.illord.com/CN/abstract/abstract9477.shtml [12] 张克非, 蒋涛, 邵龙, 等.基于新型模糊PID控制单元的LD精密温控研究[J].光学精密工程, 2017, 25(3):648-655.http://www.eope.net/gxjmgc/CN/abstract/abstract16932.shtmlZHANG K F, JIANG T, SHAO L, et al.. Research on precision temperature control of laser diode based on the novel fuzzy-PID control unit[J]. Opt. Precision Eng., 2017, 25(3):648-655.(in Chinese)http://www.eope.net/gxjmgc/CN/abstract/abstract16932.shtml [13] YU H H, HU P, AN J ZH, et al.. Thermal blooming effects of gas on laser propagation in a closed tube[J]. Proc. SPIE, 2014, 9255:92552Z1-10.doi:10.1117/12.2065127.full [14] 孙运强. 内通道传输的气体热效应研究[D]. 长沙: 国防科学技术大学, 2011: 11-12.http://cdmd.cnki.com.cn/Article/CDMD-90002-1011303324.htmSUN Y Q. Study on the Thermal blooming of beam propagation in the inner channel[D]. Changsha: National University of Defense Technology. 2011: 11-12. (in Chinese)http://cdmd.cnki.com.cn/Article/CDMD-90002-1011303324.htm [15] 刘剑峰, 龙夫年, 张伟, 等.基于泽尼克多项式进行面形误差拟合的频域分析[J].光学学报, 2005, 25(8):1062-1066.http://www.docin.com/p-728556427.htmlLIU J F, LONG F N, ZHANG W, et al.. Frequency domain analysis of surface figure fitting based on zernike polynomials[J]. Acta Optica Sinica, 2005, 25(8):1062-1066.(in Chinese)http://www.docin.com/p-728556427.html -
