Research progress of the laser vibration measurement techniques for acoustic-to-seismic coupling landmine detection

doi:10.37188/CO.2020-0134
Funds:Supported by National Natural Science Foundation of China (No. 41704123, No. 61773249); the Science and Technology on Near-Surface Detection Laboratory (No. TCGZ2018A007, No. TCGZ2020C003)
More Information
  • Author Bio:

    LI Jin-hui(1986—), male, Ph.D., he was born in Xiangtan, Hunan Province in 1986, and received his Ph.D. degree from National University of Defense Technology in 2015. Currently, he is an engineer in the Science and Technology on Near-surface Detection Laboratory. His main research interests include precision detection technology. E-mail:fabry_perot2020@126.com

    WANG Chi(1982—), male, Ph.D., he was born in Taikang, Henan province in 1982, and received his Ph.D. degree in measurement technology and instruments from Tianjin University in 2009. Currently, he is a professor in School of Mechatronic Engineering and Automation, Shanghai University. His main research interests include optical detection technology. E-mail:wangchi@shu.edu.cn

  • Corresponding author:wangchi@shu.edu.cn
  • Received Date:10 Aug 2020
  • Rev Recd Date:07 Sep 2020
  • Available Online:28 Apr 2021
  • Publish Date:14 May 2021
  • Acoustic-to-seismic coupling landmine detection technology based on the unique mechanical characteristics of landmines and the acoustic-to-seismic coupling principle has broad application prospects in safe and effective detection of landmines. However, a significant amount of work must be done to study the practical landmine detection system. Among them, the acoustic coupled surface vibration signals are very weak and complicated, which has always been a challenging problem to detect such signals accurately and quickly. In this paper, the non-contact laser measurement techniques of surface vibrations based on the principle of the acoustic-to-seismic coupling landmine detection technology were reviewed, including laser Doppler interferometry, electronic speckle pattern interferometry and laser self-mixing interferometry, etc., and the application feasibility of electronic speckle-shearing pattern interferometry in acoustic-to-seismic coupling landmine detection was analyzed.
